4PEG | pdb_00004peg

Dbr1 in complex with guanosine-5'-monophosphate


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:
    0.229 (Depositor), 0.231 (DCC)
  • R-Value Work:
    0.197 (Depositor), 0.198 (DCC)
  • R-Value Observed:
    0.199 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4PEG

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

Structural basis of lariat RNA recognition by the intron debranching enzyme Dbr1.

Montemayor, E.J.Katolik, A.Clark, N.E.Taylor, A.B.Schuermann, J.P.Combs, D.J.Johnsson, R.Holloway, S.P.Stevens, S.W.Damha, M.J.Hart, P.J.

(2014) Nucleic Acids Res 42: 10845-10855

  • DOI: https://doi.org/10.1093/nar/gku725
  • Primary Citation Related Structures:
    4PEF, 4PEG, 4PEH, 4PEI

  • PubMed Abstract:

    The enzymatic processing of cellular RNA molecules requires selective recognition of unique chemical and topological features. The unusual 2',5'-phosphodiester linkages in RNA lariats produced by the spliceosome must be hydrolyzed by the intron debranching enzyme (Dbr1) before they can be metabolized or processed into essential cellular factors, such as snoRNA and miRNA. Dbr1 is also involved in the propagation of retrotransposons and retroviruses, although the precise role played by the enzyme in these processes is poorly understood. Here, we report the first structures of Dbr1 alone and in complex with several synthetic RNA compounds that mimic the branchpoint in lariat RNA. The structures, together with functional data on Dbr1 variants, reveal the molecular basis for 2',5'-phosphodiester recognition and explain why the enzyme lacks activity toward 3',5'-phosphodiester linkages. The findings illuminate structure/function relationships in a unique enzyme that is central to eukaryotic RNA metabolism and set the stage for the rational design of inhibitors that may represent novel therapeutic agents to treat retroviral infections and neurodegenerative disease.


  • Organizational Affiliation
    • Department of Biochemistry, The University of Texas Health Science Center, San Antonio, TX 78229, USA X-ray Crystallography Core Laboratory, The University of Texas Health Science Center, San Antonio, TX 78229, USA.

Macromolecule Content

  • Total Structure Weight: 212.33 kDa
  • Atom Count: 15,560
  • Modeled Residue Count: 1,746
  • Deposited Residue Count: 1,800
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
RNA lariat debranching enzyme, putative
A, B, C, D, E
360Entamoeba histolyticaMutation(s): 0
Gene Names: EHI_062730
EC: 3.1.4
UniProt
Find proteins for C4M1P9 (Entamoeba histolytica (strain ATCC 30459 / HM-1:IMSS / ABRM))
Explore C4M1P9
Go to UniProtKB:  C4M1P9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4M1P9
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
5GP

Query on 5GP



Download:Ideal Coordinates CCD File
G [auth A],
K [auth B],
O [auth C],
R [auth D],
U [auth E]
GUANOSINE-5'-MONOPHOSPHATE
C10 H14 N5 O8 P
RQFCJASXJCIDSX-UUOKFMHZSA-N
SO4

Query on SO4



Download:Ideal Coordinates CCD File
H [auth A],
L [auth B],
P [auth C],
S [auth D],
V [auth E]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL

Query on GOL



Download:Ideal Coordinates CCD File
I [auth A],
M [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
MN

Query on MN



Download:Ideal Coordinates CCD File
F [auth A],
J [auth B],
N [auth C],
Q [auth D],
T [auth E]
MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:  0.229 (Depositor), 0.231 (DCC)
  • R-Value Work:  0.197 (Depositor), 0.198 (DCC)
  • R-Value Observed: 0.199 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 72.831α = 90
b = 141.499β = 90
c = 212.942γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2014-08-27
    Type: Initial release
  • Version 1.1: 2014-10-01
    Changes: Database references
  • Version 1.2: 2015-02-04
    Changes: Derived calculations
  • Version 1.3: 2023-12-27
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description, Source and taxonomy
