4NOB

Crystal structure of the 1st Ig domain from mouse Polymeric Immunoglobulin receptor [PSI-NYSGRC-006220]

• PDB DOI: https://doi.org/10.2210/pdb4NOB/pdb

• Classification: IMMUNE SYSTEM
• Organism(s): Mus musculus
• Expression System: Trichoplusia ni
• Mutation(s): No


• Deposited: 2013-11-19 Released: 2013-12-04
• Deposition Author(s): Kumar, P.R., Banu, R., Bhosle, R., Calarese, D.A., Celikgil, A., Chamala, S., Chan, M.K., Chowdhury, S., Fiser, A., Garforth, S.J., Glenn, A.S., Hillerich, B., Khafizov, K., Attonito, J., Love, J.D., Patel, H., Patel, R., Seidel, R.D., Smith, B., Stead, M., Casadevall, A., Almo, S.C., New York Structural Genomics Research Consortium (NYSGRC), Atoms-to-Animals: The Immune Function Network (IFN)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.51 Å
• R-Value Free: 0.189
• R-Value Work: 0.161
• R-Value Observed: 0.163

Starting Model: experimental

Literature

Crystal structure of the 1st Ig domain from mouse Polymeric Immunoglobulin receptor

Kumar, P.R., Casadevall, A., Almo, S.C.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 14.37 kDa
• Atom Count: 1,001
• Modelled Residue Count: 112
• Deposited Residue Count: 126
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Polymeric immunoglobulin receptor	A	126	Mus musculus	Mutation(s): 0  Gene Names: Pigr
UniProt
Find proteins for O70570 (Mus musculus) Explore O70570  Go to UniProtKB:  O70570
Glycosylation
Glycosylation Sites: 1		Go to GlyGen: O70570-1

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NAG	B [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C8 H15 N O6 OVRNDRQMDRJTHS-FMDGEEDCSA-N
EDO	D [auth A], E [auth A], F [auth A]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N
MG	C [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.51 Å
• R-Value Free: 0.189
• R-Value Work: 0.161
• R-Value Observed: 0.163
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 40.275	α = 90
b = 46.803	β = 90
c = 62.062	γ = 90

Software Package:

Software Name	Purpose
SCALEPACK	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
CBASS	data collection
HKL-3000	data reduction
MOLREP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2013-12-04
Deposition Author(s): Kumar, P.R., Banu, R., Bhosle, R., Calarese, D.A., Celikgil, A., Chamala, S., Chan, M.K., Chowdhury, S., Fiser, A., Garforth, S.J., Glenn, A.S., Hillerich, B., Khafizov, K., Attonito, J., Love, J.D., Patel, H., Patel, R., Seidel, R.D., Smith, B., Stead, M., Casadevall, A., Almo, S.C., New York Structural Genomics Research Consortium (NYSGRC), Atoms-to-Animals: The Immune Function Network (IFN)

Revision History

• Version 1.0: 2013-12-04
  Type: Initial release

• Version 1.1: 2020-07-29
  Type: Remediation
  Reason: Carbohydrate remediation
  Changes: Data collection, Database references, Derived calculations, Structure summary
• Version 1.2: 2023-09-20
  Changes: Data collection, Database references, Refinement description, Structure summary
• Version 1.3: 2024-10-16
  Changes: Structure summary
