4MNK | pdb_00004mnk

Crystal Structure of GH18 Chitinase from Cycas revoluta in complex with (GlcNAc)3

PDB DOI: https://doi.org/10.2210/pdb4MNK/pdb

Classification: HYDROLASE
Organism(s): Cycas revoluta
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2013-09-11 Released: 2014-10-22
Deposition Author(s): Umemoto, N., Numata, T., Ohnuma, T., Osawa, T., Taira, T., Fukamizo, T.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.29 Å
R-Value Free:
0.199 (Depositor), 0.198 (DCC)
R-Value Work:
0.182 (Depositor), 0.182 (DCC)
R-Value Observed:
0.183 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 2.1 of the entry. See complete history.

Literature

Crystal Structure of GH18 Chitinase from Cycad, Cycas revoluta

Umemoto, N., Numata, T., Ohnuma, T., Osawa, T., Taira, T., Fukamizo, T.

To be published.

Macromolecule Content

Total Structure Weight: 39.99 kDa
Atom Count: 3,157
Modeled Residue Count: 342
Deposited Residue Count: 348
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Chitinase A	A	348	Cycas revoluta	Mutation(s): 0 Gene Names: crchiA EC: 3.2.1.14
UniProt
Find proteins for Q4W6L6 (Cycas revoluta) Explore Q4W6L6 Go to UniProtKB: Q4W6L6
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q4W6L6
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	B	3		N/A	Interactions Focus chain B Interactions & Density Focus chain B
Glycosylation Resources
GlyTouCan: G47362BJ GlyCosmos: G47362BJ GlyGen: G47362BJ

Entity ID: 3
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	C	2		N/A	Interactions Focus chain C Interactions & Density Focus chain C
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
B3P Query on B3P Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	2-[3-(2-HYDROXY-1,1-DIHYDROXYMETHYL-ETHYLAMINO)-PROPYLAMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL C₁₁ H₂₆ N₂ O₆ HHKZCCWKTZRCCL-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
ACT Query on ACT Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]

Biologically Interesting Molecules (External Reference)

1 Unique

Entity ID: 2
ID	Chains	Name	Type/Class	2D Diagram	3D Interactions
PRD_900017 Query on PRD_900017	B	triacetyl-beta-chitotriose	Oligosaccharide / Inhibitor		Interactions Focus chain B Interactions & Density Focus chain B

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.29 Å
R-Value Free: 0.199 (Depositor), 0.198 (DCC)
R-Value Work: 0.182 (Depositor), 0.182 (DCC)
R-Value Observed: 0.183 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 57.822	α = 90
b = 64.036	β = 90
c = 85.986	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
MOLREP	phasing
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2014-10-22

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2014-10-22
Type: Initial release
Version 2.0: 2020-07-29
Type: Remediation
Reason: Carbohydrate remediation
Changes: Atomic model, Data collection, Database references, Derived calculations, Structure summary
Version 2.1: 2023-11-08
Changes: Data collection, Database references, Refinement description, Structure summary
