4M8K | pdb_00004m8k

Crystal structure of a putative GDSL-like lipase (BACUNI_00748) from Bacteroides uniformis ATCC 8492 at 1.90 A resolution

PDB DOI: https://doi.org/10.2210/pdb4M8K/pdb

Classification: HYDROLASE
Organism(s): Bacteroides uniformis ATCC 8492
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2013-08-13 Released: 2013-08-28
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.206 (Depositor), 0.216 (DCC)
R-Value Work:
0.160 (Depositor), 0.170 (DCC)
R-Value Observed:
0.163 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4M8K

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of a hypothetical protein (BACUNI_00748) from Bacteroides uniformis ATCC 8492 at 1.90 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 54.42 kDa
Atom Count: 3,791
Modeled Residue Count: 425
Deposited Residue Count: 472
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
hypothetical protein, GDSL-like Lipase/Acylhydrolase family protein	A, B	236	Bacteroides uniformis ATCC 8492	Mutation(s): 0 Gene Names: BACUNI_00748, ZP_02069338.1

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ACT Query on ACT Download:Ideal Coordinates CCD File SDF format, chain F [auth B] SDF format, chain E [auth B] SDF format, chain C [auth A] MOL2 format, chain F [auth B] MOL2 format, chain E [auth B] MOL2 format, chain C [auth A] mmCIF format, chain F [auth B] mmCIF format, chain E [auth B] mmCIF format, chain C [auth A]	C [auth A], E [auth B], F [auth B]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain C [auth A] Focus chain E [auth B] Focus chain F [auth B] Interactions & Density Focus chain C [auth A] Focus chain E [auth B] Focus chain F [auth B]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain G [auth B] SDF format, chain D [auth A] MOL2 format, chain G [auth B] MOL2 format, chain D [auth A] mmCIF format, chain G [auth B] mmCIF format, chain D [auth A]	D [auth A], G [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Focus chain G [auth B] Interactions & Density Focus chain D [auth A] Focus chain G [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.206 (Depositor), 0.216 (DCC)
R-Value Work: 0.160 (Depositor), 0.170 (DCC)
R-Value Observed: 0.163 (Depositor)

Diffraction Data:

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 49.244	α = 90
b = 72.319	β = 91.53
c = 62.9	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SHELX	phasing
SHARP	phasing
XSCALE	data scaling
REFMAC	refinement
XDS	data reduction
SHELXD	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2013-08-28

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2013-08-28
Type: Initial release
Version 1.1: 2014-12-24
Changes: Structure summary
Version 1.2: 2017-11-15
Changes: Refinement description
Version 1.3: 2018-01-24
Changes: Database references
Version 1.4: 2023-02-01
Changes: Database references, Derived calculations
Version 1.5: 2024-11-20
Changes: Data collection, Structure summary
