4KW9 | pdb_00004kw9

Crystal Structure of Green Fluorescent Protein

PDB DOI: https://doi.org/10.2210/pdb4KW9/pdb

Classification: FLUORESCENT PROTEIN
Organism(s): Aequorea victoria
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2013-05-23 Released: 2014-04-09
Deposition Author(s): Barnard, T.J., Yu, X., Noinaj, N., Taraska, J.W.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.210 (Depositor), 0.215 (DCC)
R-Value Work:
0.175 (Depositor), 0.178 (DCC)
R-Value Observed:
0.178 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4KW9

This is version 1.2 of the entry. See complete history.

Literature

Crystal Structure of Green Fluorescent Protein

Barnard, T.J., Yu, X., Noinaj, N., Taraska, J.W.

To be published.

Macromolecule Content

Total Structure Weight: 27.59 kDa
Atom Count: 1,959
Modeled Residue Count: 223
Deposited Residue Count: 239
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Green fluorescent protein	A	239	Aequorea victoria	Mutation(s): 5 Gene Names: GFP
UniProt
Find proteins for P42212 (Aequorea victoria) Explore P42212 Go to UniProtKB: P42212
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P42212
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] MOL2 format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] mmCIF format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A]	B [auth A], C [auth A], D [auth A], E [auth A], F [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain G [auth A] MOL2 format, chain G [auth A] mmCIF format, chain G [auth A]	G [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain G [auth A] Interactions & Density Focus chain G [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
CRO Query on CRO	A	L-PEPTIDE LINKING	C₁₅ H₁₇ N₃ O₅		THR, TYR, GLY

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.210 (Depositor), 0.215 (DCC)
R-Value Work: 0.175 (Depositor), 0.178 (DCC)
R-Value Observed: 0.178 (Depositor)

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 72.798	α = 90
b = 72.798	β = 90
c = 114.942	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
PHASER	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction
SERGUI	data collection

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2014-04-09

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2014-04-09
Type: Initial release
Version 1.1: 2022-12-21
Changes: Database references, Derived calculations
Version 1.2: 2024-11-06
Changes: Data collection, Structure summary
