4KR4 | pdb_00004kr4

Salmonella typhi OmpF complex with Ampicillin

• PDB DOI: https://doi.org/10.2210/pdb4KR4/pdb

• Classification: MEMBRANE PROTEIN
• Organism(s): Salmonella enterica subsp. enterica serovar Typhi
• Expression System: Escherichia coli
• Mutation(s): No
• Membrane Protein: Yes  PDBTMMemProtMD


• Deposited: 2013-05-16 Released: 2014-05-28
• Deposition Author(s): Madhuranayaki, T., Balasubramaniam, D., Krishnaswamy, S.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 3.80 Å
• R-Value Free:
  0.366 (Depositor), 0.362 (DCC)
• R-Value Work:
  0.286 (Depositor), 0.284 (DCC)
• R-Value Observed:
  0.290 (Depositor)

Starting Model: experimental

Literature

Salmonella typhi OmpF complex with Ampicillin

Madhuranayaki, T., Balasubramaniam, D., Krishnaswamy, S.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C3  (Explore in 3D)
Global Stoichiometry: Homo 3-mer - A3

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 114.01 kDa
• Atom Count: 7,501
• Modeled Residue Count: 1,013
• Deposited Residue Count: 1,023
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Outer membrane protein F	A, B, C	341	Salmonella enterica subsp. enterica serovar Typhi	Mutation(s): 0  Gene Names: ompF Membrane Entity: Yes
UniProt
Find proteins for P37432 (Salmonella typhimurium (strain LT2 / SGSC1412 / ATCC 700720)) Explore P37432  Go to UniProtKB:  P37432

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
AIC	D [auth C]	(2S,5R,6R)-6-{[(2R)-2-AMINO-2-PHENYLETHANOYL]AMINO}-3,3-DIMETHYL-7-OXO-4-THIA-1-AZABICYCLO[3.2.0]HEPTANE-2-CARBOXYLIC ACID C16 H19 N3 O4 S AVKUERGKIZMTKX-NJBDSQKTSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 3.80 Å
• R-Value Free:  0.366 (Depositor), 0.362 (DCC)
• R-Value Work:  0.286 (Depositor), 0.284 (DCC)
• R-Value Observed: 0.290 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 85.12	α = 90
b = 138.48	β = 90
c = 150.99	γ = 90

Software Package:

Software Name	Purpose
SCALA	data scaling
PHASER	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
MOSFLM	data reduction

Structure Validation

Entry History

Deposition Data

• Released Date: 2014-05-28
Deposition Author(s): Madhuranayaki, T., Balasubramaniam, D., Krishnaswamy, S.

Revision History

• Version 1.0: 2014-05-28
  Type: Initial release

• Version 1.1: 2023-11-08
  Changes: Data collection, Database references, Derived calculations, Refinement description
