4IZO | pdb_00004izo

Crystal structure of kinase Phosphoribosylaminoimidazole carboxylase, ATPase subunit from Burkholderia thailandensis

PDB DOI: https://doi.org/10.2210/pdb4IZO/pdb

Classification: LYASE
Organism(s): Burkholderia thailandensis E264
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2013-01-30 Released: 2013-02-27
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free:
0.214 (Depositor), 0.221 (DCC)
R-Value Work:
0.182 (Depositor), 0.190 (DCC)
R-Value Observed:
0.184 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4IZO

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of kinase Phosphoribosylaminoimidazole carboxylase, ATPase subunit from Burkholderia thailandensis

SSGCID, Abendroth, J., Lorimer, D., Edwards, T.E.

To be published.

Macromolecule Content

Total Structure Weight: 43.79 kDa
Atom Count: 3,098
Modeled Residue Count: 376
Deposited Residue Count: 419
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Phosphoribosylaminoimidazole carboxylase, ATPase subunit	A	419	Burkholderia thailandensis E264	Mutation(s): 0 Gene Names: BTH_I0668, purK EC: 4.1.1.21 (PDB Primary Data), 6.3.4.18 (UniProt)
UniProt
Find proteins for Q2T0S5 (Burkholderia thailandensis (strain ATCC 700388 / DSM 13276 / CCUG 48851 / CIP 106301 / E264)) Explore Q2T0S5 Go to UniProtKB: Q2T0S5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q2T0S5
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free: 0.214 (Depositor), 0.221 (DCC)
R-Value Work: 0.182 (Depositor), 0.190 (DCC)
R-Value Observed: 0.184 (Depositor)

Diffraction Data:

Space Group: P 6₁ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.93	α = 90
b = 53.93	β = 90
c = 465.92	γ = 120

Software Package:

Software Name	Purpose
XSCALE	data scaling
PHASER	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
Blu-Ice	data collection
XDS	data reduction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2013-02-27

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History (Full details and data files)

Version 1.0: 2013-02-27
Type: Initial release
Version 1.1: 2023-09-20
Changes: Data collection, Database references, Refinement description
