4I5Y | pdb_00004i5y

Insulin protein crystallization via langmuir-blodgett

PDB DOI: https://doi.org/10.2210/pdb4I5Y/pdb

Classification: HORMONE
Organism(s): Bos taurus
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2012-11-29 Released: 2013-11-20
Deposition Author(s): Belmonte, L., Pechkova, E., Bragazzi, N., Nicolini, C.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.222 (Depositor), 0.221 (DCC)
R-Value Work:
0.182 (Depositor), 0.181 (DCC)
R-Value Observed:
0.184 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4I5Y

This is version 1.1 of the entry. See complete history.

Literature

A Review OF THE STRATEGIES FOR OBTAINING HIGH QUALITY CRYSTALS UTILIZING NANOTECHNOLOGIES AND SPACE

Pechkova, E., Bragazzi, N., Belmonte, L., Nicolini, C.

(2013) Crit Rev Eukaryot Gene Expr

Macromolecule Content

Total Structure Weight: 5.74 kDa
Atom Count: 452
Modeled Residue Count: 51
Deposited Residue Count: 51
Unique protein chains: 2

Macromolecules

Find similar proteins by: Sequence | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Insulin	A	21	Bos taurus	Mutation(s): 0 Gene Names: INS
UniProt
Find proteins for P01317 (Bos taurus) Explore P01317 Go to UniProtKB: P01317
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P01317
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Insulin	B	30	Bos taurus	Mutation(s): 0 Gene Names: INS
UniProt
Find proteins for P01317 (Bos taurus) Explore P01317 Go to UniProtKB: P01317
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P01317
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.222 (Depositor), 0.221 (DCC)
R-Value Work: 0.182 (Depositor), 0.181 (DCC)
R-Value Observed: 0.184 (Depositor)

Space Group: I 2₁ 3

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 78.2	α = 90
b = 78.2	β = 90
c = 78.2	γ = 90

Software Package:

Software Name	Purpose
MOSFLM	data reduction
SCALA	data scaling
MOLREP	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2013-11-20

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2013-11-20
Type: Initial release
Version 1.1: 2024-11-20
Changes: Data collection, Database references, Structure summary
