4H09 | pdb_00004h09

Crystal structure of a leucine-rich repeat protein (EUBVEN_01088) from Eubacterium ventriosum ATCC 27560 at 2.50 A resolution

PDB DOI: https://doi.org/10.2210/pdb4H09/pdb

Classification: PROTEIN BINDING
Organism(s): Eubacterium ventriosum ATCC 27560
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2012-09-07 Released: 2012-10-10
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free:
0.209 (Depositor), 0.216 (DCC)
R-Value Work:
0.176 (Depositor), 0.183 (DCC)
R-Value Observed:
0.177 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4H09

This is version 1.4 of the entry. See complete history.

Literature

Crystal structure of a hypothetical leucine rich repeat protein (EUBVEN_01088) from Eubacterium ventriosum ATCC 27560 at 2.50 A resolution (CASP Target)

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 210.68 kDa
Atom Count: 14,625
Modeled Residue Count: 1,869
Deposited Residue Count: 1,895
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hypothetical leucine rich repeat protein	A, B, C, D, E	379	Eubacterium ventriosum ATCC 27560	Mutation(s): 0 Gene Names: EUBVEN_01088
UniProt
Find proteins for A5Z5V6 (Eubacterium ventriosum ATCC 27560) Explore A5Z5V6 Go to UniProtKB: A5Z5V6
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A5Z5V6
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PEG Query on PEG Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain FA [auth D] SDF format, chain G [auth A] SDF format, chain GA [auth D] MOL2 format, chain F [auth A] MOL2 format, chain FA [auth D] MOL2 format, chain G [auth A] MOL2 format, chain GA [auth D] mmCIF format, chain F [auth A] mmCIF format, chain FA [auth D] mmCIF format, chain G [auth A] mmCIF format, chain GA [auth D]	F [auth A], FA [auth D], G [auth A], GA [auth D]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain FA [auth D] Focus chain G [auth A] Focus chain GA [auth D] Interactions & Density Focus chain F [auth A] Focus chain FA [auth D] Focus chain G [auth A] Focus chain GA [auth D]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain AA [auth C] SDF format, chain BA [auth C] SDF format, chain CA [auth C] SDF format, chain DA [auth C] SDF format, chain EA [auth C] SDF format, chain H [auth A] SDF format, chain HA [auth D] SDF format, chain I [auth A] SDF format, chain IA [auth D] SDF format, chain J [auth A] SDF format, chain JA [auth D] SDF format, chain K [auth A] SDF format, chain KA [auth D] SDF format, chain L [auth A] SDF format, chain LA [auth D] SDF format, chain M [auth A] SDF format, chain MA [auth D] SDF format, chain N [auth A] SDF format, chain NA [auth D] SDF format, chain O [auth A] SDF format, chain OA [auth D] SDF format, chain P [auth A] SDF format, chain PA [auth E] SDF format, chain Q [auth A] SDF format, chain QA [auth E] SDF format, chain R [auth A] SDF format, chain RA [auth E] SDF format, chain S [auth A] SDF format, chain SA [auth E] SDF format, chain T [auth B] SDF format, chain TA [auth E] SDF format, chain U [auth B] SDF format, chain UA [auth E] SDF format, chain V [auth B] SDF format, chain W [auth B] SDF format, chain X [auth B] SDF format, chain Y [auth B] SDF format, chain Z [auth B] MOL2 format, chain AA [auth C] MOL2 format, chain BA [auth C] MOL2 format, chain CA [auth C] MOL2 format, chain DA [auth C] MOL2 format, chain EA [auth C] MOL2 format, chain H [auth A] MOL2 format, chain HA [auth D] MOL2 format, chain I [auth A] MOL2 format, chain IA [auth D] MOL2 format, chain J [auth A] MOL2 format, chain JA [auth D] MOL2 format, chain K [auth A] MOL2 format, chain KA [auth D] MOL2 format, chain L [auth A] MOL2 format, chain LA [auth D] MOL2 format, chain M [auth A] MOL2 format, chain MA [auth D] MOL2 format, chain N [auth A] MOL2 format, chain NA [auth D] MOL2 format, chain O [auth A] MOL2 format, chain OA [auth D] MOL2 format, chain P [auth A] MOL2 format, chain PA [auth E] MOL2 format, chain Q [auth A] MOL2 format, chain QA [auth E] MOL2 format, chain R [auth A] MOL2 format, chain RA [auth E] MOL2 format, chain S [auth A] MOL2 format, chain SA [auth E] MOL2 format, chain T [auth B] MOL2 format, chain TA [auth E] MOL2 format, chain U [auth B] MOL2 format, chain UA [auth E] MOL2 format, chain V [auth B] MOL2 format, chain W [auth B] MOL2 format, chain X [auth B] MOL2 format, chain Y [auth B] MOL2 format, chain Z [auth B] mmCIF format, chain AA [auth C] mmCIF format, chain BA [auth C] mmCIF format, chain CA [auth C] mmCIF format, chain DA [auth C] mmCIF format, chain EA [auth C] mmCIF format, chain H [auth A] mmCIF format, chain HA [auth D] mmCIF format, chain I [auth A] mmCIF format, chain IA [auth D] mmCIF format, chain J [auth A] mmCIF format, chain JA [auth D] mmCIF format, chain K [auth A] mmCIF format, chain KA [auth D] mmCIF format, chain L [auth A] mmCIF format, chain LA [auth D] mmCIF format, chain M [auth A] mmCIF format, chain MA [auth D] mmCIF format, chain N [auth A] mmCIF format, chain NA [auth D] mmCIF format, chain O [auth A] mmCIF format, chain OA [auth D] mmCIF format, chain P [auth A] mmCIF format, chain PA [auth E] mmCIF format, chain Q [auth A] mmCIF format, chain QA [auth E] mmCIF format, chain R [auth A] mmCIF format, chain RA [auth E] mmCIF format, chain S [auth A] mmCIF format, chain SA [auth E] mmCIF format, chain T [auth B] mmCIF format, chain TA [auth E] mmCIF format, chain U [auth B] mmCIF format, chain UA [auth E] mmCIF format, chain V [auth B] mmCIF format, chain W [auth B] mmCIF format, chain X [auth B] mmCIF format, chain Y [auth B] mmCIF format, chain Z [auth B]	AA [auth C] BA [auth C] CA [auth C] DA [auth C] EA [auth C] AA [auth C], BA [auth C], CA [auth C], DA [auth C], EA [auth C], H [auth A], HA [auth D], I [auth A], IA [auth D], J [auth A], JA [auth D], K [auth A], KA [auth D], L [auth A], LA [auth D], M [auth A], MA [auth D], N [auth A], NA [auth D], O [auth A], OA [auth D], P [auth A], PA [auth E], Q [auth A], QA [auth E], R [auth A], RA [auth E], S [auth A], SA [auth E], T [auth B], TA [auth E], U [auth B], UA [auth E], V [auth B], W [auth B], X [auth B], Y [auth B], Z [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain AA [auth C] Focus chain BA [auth C] Focus chain CA [auth C] Focus chain DA [auth C] Focus chain EA [auth C] Focus chain H [auth A] Focus chain HA [auth D] Focus chain I [auth A] Focus chain IA [auth D] Focus chain J [auth A] Focus chain JA [auth D] Focus chain K [auth A] Focus chain KA [auth D] Focus chain L [auth A] Focus chain LA [auth D] Focus chain M [auth A] Focus chain MA [auth D] Focus chain N [auth A] Focus chain NA [auth D] Focus chain O [auth A] Focus chain OA [auth D] Focus chain P [auth A] Focus chain PA [auth E] Focus chain Q [auth A] Focus chain QA [auth E] Focus chain R [auth A] Focus chain RA [auth E] Focus chain S [auth A] Focus chain SA [auth E] Focus chain T [auth B] Focus chain TA [auth E] Focus chain U [auth B] Focus chain UA [auth E] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B] Interactions & Density Focus chain AA [auth C] Focus chain BA [auth C] Focus chain CA [auth C] Focus chain DA [auth C] Focus chain EA [auth C] Focus chain H [auth A] Focus chain HA [auth D] Focus chain I [auth A] Focus chain IA [auth D] Focus chain J [auth A] Focus chain JA [auth D] Focus chain K [auth A] Focus chain KA [auth D] Focus chain L [auth A] Focus chain LA [auth D] Focus chain M [auth A] Focus chain MA [auth D] Focus chain N [auth A] Focus chain NA [auth D] Focus chain O [auth A] Focus chain OA [auth D] Focus chain P [auth A] Focus chain PA [auth E] Focus chain Q [auth A] Focus chain QA [auth E] Focus chain R [auth A] Focus chain RA [auth E] Focus chain S [auth A] Focus chain SA [auth E] Focus chain T [auth B] Focus chain TA [auth E] Focus chain U [auth B] Focus chain UA [auth E] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B, C, D, E	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free: 0.209 (Depositor), 0.216 (DCC)
R-Value Work: 0.176 (Depositor), 0.183 (DCC)
R-Value Observed: 0.177 (Depositor)

Diffraction Data:

Space Group: P 6₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 105.513	α = 90
b = 105.513	β = 90
c = 361.567	γ = 120

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SOLVE	phasing
SCALA	data scaling
BUSTER-TNT	refinement
MOSFLM	data reduction
BUSTER	refinement

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2012-10-10

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2012-10-10
Type: Initial release
Version 1.1: 2014-12-24
Changes: Structure summary
Version 1.2: 2017-11-15
Changes: Refinement description
Version 1.3: 2023-02-01
Changes: Database references, Derived calculations
Version 1.4: 2024-11-06
Changes: Data collection, Structure summary
