4GWF

Crystal structure of the tyrosine phosphatase SHP-2 with Y279C mutation

PDB DOI: https://doi.org/10.2210/pdb4GWF/pdb

Classification: HYDROLASE
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2012-09-03 Released: 2013-09-04
Deposition Author(s): Qiu, W., Lin, A., Hutchinson, A., Romanov, V., Ruzanov, M., Thompson, C., Lam, K., Kisselman, G., Battaile, K., Chirgadze, N.Y.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free: 0.243
R-Value Work: 0.210
R-Value Observed: 0.211

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of the tyrosine phosphatase SHP-2 with Y279C mutation

Qiu, W., Lin, A., Hutchinson, A., Romanov, V., Ruzanov, M., Thompson, C., Lam, K., Kisselman, G., Battaile, K., Chirgadze, N.Y.

To be published.

Macromolecule Content

Total Structure Weight: 130.14 kDa
Atom Count: 8,367
Modelled Residue Count: 990
Deposited Residue Count: 1,120
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Tyrosine-protein phosphatase non-receptor type 11	A, B	560	Homo sapiens	Mutation(s): 1 Gene Names: PTPN11, PTP2C, SHPTP2 EC: 3.1.3.48
UniProt & NIH Common Fund Data Resources
Find proteins for Q06124 (Homo sapiens) Explore Q06124 Go to UniProtKB: Q06124
PHAROS: Q06124 GTEx: ENSG00000179295
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q06124
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PGE Query on PGE Download Ideal Coordinates CCD File SDF format, chain K [auth A] MOL2 format, chain K [auth A] mmCIF format, chain K [auth A]	K [auth A]	TRIETHYLENE GLYCOL C₆ H₁₄ O₄ ZIBGPFATKBEMQZ-UHFFFAOYSA-N		Interactions Focus chain K [auth A] Interactions & Density Focus chain K [auth A]
PEG Query on PEG Download Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain J [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A]	I [auth A], J [auth A]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain J [auth A] Interactions & Density Focus chain I [auth A] Focus chain J [auth A]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain H [auth A] MOL2 format, chain H [auth A] mmCIF format, chain H [auth A]	H [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Interactions & Density Focus chain H [auth A]
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain L [auth B] SDF format, chain M [auth B] SDF format, chain N [auth B] SDF format, chain O [auth B] SDF format, chain P [auth B] SDF format, chain Q [auth B] SDF format, chain R [auth B] SDF format, chain S [auth B] SDF format, chain T [auth B] SDF format, chain U [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain L [auth B] MOL2 format, chain M [auth B] MOL2 format, chain N [auth B] MOL2 format, chain O [auth B] MOL2 format, chain P [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] MOL2 format, chain S [auth B] MOL2 format, chain T [auth B] MOL2 format, chain U [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain L [auth B] mmCIF format, chain M [auth B] mmCIF format, chain N [auth B] mmCIF format, chain O [auth B] mmCIF format, chain P [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain R [auth B] mmCIF format, chain S [auth B] mmCIF format, chain T [auth B] mmCIF format, chain U [auth B]	C [auth A] D [auth A] E [auth A] F [auth A] G [auth A] C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], L [auth B], M [auth B], N [auth B], O [auth B], P [auth B], Q [auth B], R [auth B], S [auth B], T [auth B], U [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free: 0.243
R-Value Work: 0.210
R-Value Observed: 0.211
Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 45.972	α = 90
b = 211.953	β = 96.63
c = 55.691	γ = 90

Software Package:

Software Name	Purpose
JBluIce-EPICS	data collection
PHASER	phasing
BUSTER	refinement
XDS	data reduction
XSCALE	data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2013-09-04

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2013-09-04
Type: Initial release
Version 1.1: 2017-11-15
Changes: Refinement description
Version 1.2: 2023-09-13
Changes: Data collection, Database references, Derived calculations, Refinement description
