4GM6 | pdb_00004gm6

Crystal structure of PfkB family carbohydrate kinase(TARGET EFI-502146 FROM Listeria grayi DSM 20601

• PDB DOI: https://doi.org/10.2210/pdb4GM6/pdb

• Classification: TRANSFERASE
• Organism(s): Listeria grayi DSM 20601
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2012-08-15 Released: 2012-09-26
• Deposition Author(s): Patskovsky, Y., Toro, R., Bhosle, R., Hillerich, B., Seidel, R.D., Washington, E., Scott Glenn, A., Chowdhury, S., Evans, B., Hammonds, J., Zencheck, W.D., Imker, H.J., Gerlt, J.A., Almo, S.C., Enzyme Function Initiative (EFI)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:
  0.218 (Depositor), 0.219 (DCC)
• R-Value Work:
  0.175 (Depositor), 0.177 (DCC)
• R-Value Observed:
  0.176 (Depositor)

Starting Model: experimental

Literature

Crystal structure of PfkB family carbohydrate kinase FROM Listeria grayi

Patskovsky, Y., Toro, R., Bhosle, R., Hillerich, B., Seidel, R.D., Washington, E., Scott Glenn, A., Chowdhury, S., Evans, B., Hammonds, J., Zencheck, W.D., Imker, H.J., Gerlt, J.A., Almo, S.C.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D3  (Explore in 3D)
Global Stoichiometry: Homo 6-mer - A6

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 236.76 kDa
• Atom Count: 16,449
• Modeled Residue Count: 1,927
• Deposited Residue Count: 2,106
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
PfkB family carbohydrate kinase	A, B, C, D, E, F	351	Listeria grayi DSM 20601	Mutation(s): 0  Gene Names: HMPREF0556_10677
UniProt
Find proteins for D7UWR6 (Listeria grayi DSM 20601) Explore D7UWR6  Go to UniProtKB:  D7UWR6

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	G [auth A], I [auth B], J [auth B], L [auth D], M [auth E]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
CL	H [auth A], K [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:  0.218 (Depositor), 0.219 (DCC)
• R-Value Work:  0.175 (Depositor), 0.177 (DCC)
• R-Value Observed: 0.176 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 107.832	α = 90
b = 109.862	β = 101.92
c = 109.592	γ = 90

Software Package:

Software Name	Purpose
PHASER	phasing
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2012-09-26
Deposition Author(s): Patskovsky, Y., Toro, R., Bhosle, R., Hillerich, B., Seidel, R.D., Washington, E., Scott Glenn, A., Chowdhury, S., Evans, B., Hammonds, J., Zencheck, W.D., Imker, H.J., Gerlt, J.A., Almo, S.C., Enzyme Function Initiative (EFI)

Revision History

• Version 1.0: 2012-09-26
  Type: Initial release

• Version 1.1: 2018-01-24
  Changes: Structure summary
• Version 1.2: 2023-09-13
  Changes: Data collection, Database references, Derived calculations, Refinement description
