4EXL | pdb_00004exl

Crystal structure of phosphate ABC transporter, periplasmic phosphate-binding protein PstS 1 (PBP1) from Streptococcus pneumoniae Canada MDR_19A

PDB DOI: https://doi.org/10.2210/pdb4EXL/pdb

Classification: TRANSPORT PROTEIN
Organism(s): Streptococcus pneumoniae str. Canada MDR_19A
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2012-04-30 Released: 2012-05-30
Deposition Author(s): Stogios, P.J., Wawrzak, Z., Kudritska, M., Minasov, G., Yim, V., Savchenko, A., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.211 (Depositor), 0.207 (DCC)
R-Value Work:
0.165 (Depositor), 0.160 (DCC)
R-Value Observed:
0.166 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of phosphate ABC transporter, periplasmic phosphate-binding protein PstS 1 (PBP1) from Streptococcus pneumoniae Canada MDR_19A

Stogios, P.J., Wawrzak, Z., Kudritska, M., Minasov, G., Yim, V., Savchenko, A., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Macromolecule Content

Total Structure Weight: 113.16 kDa
Atom Count: 9,277
Modeled Residue Count: 1,044
Deposited Residue Count: 1,060
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Phosphate-binding protein pstS 1	A, B, C, D	265	Streptococcus pneumoniae str. Canada MDR_19A	Mutation(s): 0 Gene Names: pstS1, SpneCM_010100007640, SP_1400
UniProt
Find proteins for Q8DPB1 (Streptococcus pneumoniae (strain ATCC BAA-255 / R6)) Explore Q8DPB1 Go to UniProtKB: Q8DPB1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8DPB1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain Q [auth D] SDF format, chain P [auth D] SDF format, chain N [auth C] SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain I [auth A] SDF format, chain H [auth A] MOL2 format, chain Q [auth D] MOL2 format, chain P [auth D] MOL2 format, chain N [auth C] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] mmCIF format, chain Q [auth D] mmCIF format, chain P [auth D] mmCIF format, chain N [auth C] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A]	H [auth A] I [auth A] K [auth B] L [auth B] N [auth C] H [auth A], I [auth A], K [auth B], L [auth B], N [auth C], P [auth D], Q [auth D]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain N [auth C] Focus chain P [auth D] Focus chain Q [auth D] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain N [auth C] Focus chain P [auth D] Focus chain Q [auth D]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain O [auth D] SDF format, chain M [auth C] SDF format, chain J [auth B] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] MOL2 format, chain O [auth D] MOL2 format, chain M [auth C] MOL2 format, chain J [auth B] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] mmCIF format, chain O [auth D] mmCIF format, chain M [auth C] mmCIF format, chain J [auth B] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A]	E [auth A] F [auth A] G [auth A] J [auth B] M [auth C] E [auth A], F [auth A], G [auth A], J [auth B], M [auth C], O [auth D]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain J [auth B] Focus chain M [auth C] Focus chain O [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain J [auth B] Focus chain M [auth C] Focus chain O [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.211 (Depositor), 0.207 (DCC)
R-Value Work: 0.165 (Depositor), 0.160 (DCC)
R-Value Observed: 0.166 (Depositor)

Diffraction Data:

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 56.633	α = 90
b = 76.501	β = 93.88
c = 111.066	γ = 90

Software Package:

Software Name	Purpose
HKL-3000	data collection
BALBES	phasing
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2012-05-30

Deposition Author(s):

Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History (Full details and data files)

Version 1.0: 2012-05-30
Type: Initial release
Version 1.1: 2013-07-03
Changes: Database references, Structure summary
Version 1.2: 2023-09-13
Changes: Data collection, Database references, Derived calculations, Refinement description
