4EPU | pdb_00004epu

Ang1 fibrinogen-related domain (FReD)

PDB DOI: https://doi.org/10.2210/pdb4EPU/pdb

Classification: SIGNALING PROTEIN
Organism(s): Homo sapiens
Expression System: Trichoplusia ni
Mutation(s): No

Deposited: 2012-04-17 Released: 2013-04-17
Deposition Author(s): Yeykal, C.C., Adams, E.J.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free:
0.201 (Depositor), 0.207 (DCC)
R-Value Work:
0.183 (Depositor), 0.190 (DCC)
R-Value Observed:
0.183 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4EPU

This is version 1.2 of the entry. See complete history.

Literature

Biochemical and structural characterization of the Ang1 fibrinogen-related domain

Yeykal, C.C., Sundaresan, L., Mrksich, M., Adams, E.J.

To be published.

Macromolecule Content

Total Structure Weight: 50.65 kDa
Atom Count: 3,752
Modeled Residue Count: 430
Deposited Residue Count: 442
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Angiopoietin-1	A, B	221	Homo sapiens	Mutation(s): 0 Gene Names: ANGPT1, KIAA0003
UniProt & NIH Common Fund Data Resources
Find proteins for Q15389 (Homo sapiens) Explore Q15389 Go to UniProtKB: Q15389
PHAROS: Q15389 GTEx: ENSG00000154188
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q15389
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth B]	C [auth A], D [auth B]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free: 0.201 (Depositor), 0.207 (DCC)
R-Value Work: 0.183 (Depositor), 0.190 (DCC)
R-Value Observed: 0.183 (Depositor)

Space Group: P 6₄

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 80.903	α = 90
b = 80.903	β = 90
c = 186.087	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
HKL-2000	data collection
HKL-3000	data reduction
HKL-3000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2013-04-17

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2013-04-17
Type: Initial release
Version 1.1: 2023-09-13
Changes: Data collection, Database references, Derived calculations, Refinement description
Version 1.2: 2024-10-30
Changes: Structure summary
