4DPI | pdb_00004dpi

BACE-1 in complex with HEA-macrocyclic inhibitor, MV078512


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:
    0.219 (Depositor), 0.226 (DCC)
  • R-Value Work:
    0.172 (Depositor), 0.175 (DCC)
  • R-Value Observed:
    0.174 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4DPI

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Highly potent macrocyclic BACE-1 inhibitors incorporating a hydroxyethylamine core: design, synthesis and X-ray crystal structures of enzyme inhibitor complexes.

Sandgren, V.Agback, T.Johansson, P.O.Lindberg, J.Kvarnstrom, I.Samuelsson, B.Belda, O.Dahlgren, A.

(2012) Bioorg Med Chem 20: 4377-4389

  • DOI: https://doi.org/10.1016/j.bmc.2012.05.039
  • Primary Citation Related Structures:
    4DPF, 4DPI

  • PubMed Abstract:

    A series of P1-P3 linked macrocyclic BACE-1 inhibitors containing a hydroxyethylamine (HEA) isostere scaffold has been synthesized. All inhibitors comprise a toluene or N-phenylmethanesulfonamide P2 moiety. Excellent BACE-1 potencies, both in enzymatic and cell-based assays, were observed in this series of target compounds, with the best candidates displaying cell-based IC(50) values in the low nanomolar range. As an attempt to improve potency, a phenyl substituent aiming at the S3 subpocket was introduced in the macrocyclic ring. X-ray analyzes were performed on selected compounds, and enzyme-inhibitor interactions are discussed.


  • Organizational Affiliation
    • Department of Chemistry, Linköping University, S-581 83 Linköping, Sweden.

Macromolecule Content

  • Total Structure Weight: 44.16 kDa
  • Atom Count: 3,355
  • Modeled Residue Count: 373
  • Deposited Residue Count: 391
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Beta-secretase 1391Homo sapiensMutation(s): 0
Gene Names: BACE1BACEKIAA1149
EC: 3.4.23.46
UniProt & NIH Common Fund Data Resources
Find proteins for P56817 (Homo sapiens)
Explore P56817
Go to UniProtKB:  P56817
PHAROS:  P56817
GTEx:  ENSG00000186318
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP56817
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
0N1

Query on 0N1



Download:Ideal Coordinates CCD File
B [auth A](4S,8E,11R)-4-[(1R)-1-hydroxy-2-{[3-(propan-2-yl)benzyl]amino}ethyl]-16-methyl-11-phenyl-6-oxa-3,12-diazabicyclo[12.3.1]octadeca-1(18),8,14,16-tetraene-2,13-dione
C34 H41 N3 O4
BEGCWPHKTGGGNN-HOQOQLLYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:  0.219 (Depositor), 0.226 (DCC)
  • R-Value Work:  0.172 (Depositor), 0.175 (DCC)
  • R-Value Observed: 0.174 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 48.6α = 90
b = 76.92β = 90
c = 104γ = 90
Software Package:
Software NamePurpose
MOSFLMdata reduction
SCALAdata scaling
PHASERphasing
REFMACrefinement
PDB_EXTRACTdata extraction
DNAdata collection

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-07-11
    Type: Initial release
  • Version 1.1: 2013-01-02
    Changes: Database references
  • Version 1.2: 2024-10-16
    Changes: Data collection, Database references, Derived calculations, Structure summary
