4AME | pdb_00004ame

TYPE III ANTIFREEZE PROTEIN ISOFORM HPLC 12 T18A


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.05 Å
  • R-Value Free:
    0.238 (Depositor)
  • R-Value Work:
    0.172 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4AME

This is version 1.4 of the entry. See complete history

Literature

Quantitative and qualitative analysis of type III antifreeze protein structure and function.

Graether, S.P.DeLuca, C.I.Baardsnes, J.Hill, G.A.Davies, P.L.Jia, Z.

(1999) J Biological Chem 274: 11842-11847

  • DOI: https://doi.org/10.1074/jbc.274.17.11842
  • Primary Citation Related Structures:
    1B7I, 1B7J, 1B7K, 1EKL, 1JAB, 1MSJ, 2AME, 2JIA, 2MSJ, 2SPG, 3AME, 4AME, 6AME, 7AME, 8AME, 8MSI, 9AME, 9MSI

  • PubMed Abstract:

    Some cold water marine fishes avoid cellular damage because of freezing by expressing antifreeze proteins (AFPs) that bind to ice and inhibit its growth; one such protein is the globular type III AFP from eel pout. Despite several studies, the mechanism of ice binding remains unclear because of the difficulty in modeling the AFP-ice interaction. To further explore the mechanism, we have determined the x-ray crystallographic structure of 10 type III AFP mutants and combined that information with 7 previously determined structures to mainly analyze specific AFP-ice interactions such as hydrogen bonds. Quantitative assessment of binding was performed using a neural network with properties of the structure as input and predicted antifreeze activity as output. Using the cross-validation method, a correlation coefficient of 0.60 was obtained between measured and predicted activity, indicating successful learning and good predictive power. A large loss in the predictive power of the neural network occurred after properties related to the hydrophobic surface were left out, suggesting that van der Waal's interactions make a significant contribution to ice binding. By combining the analysis of the neural network with antifreeze activity and x-ray crystallographic structures of the mutants, we extend the existing ice-binding model to a two-step process: 1) probing of the surface for the correct ice-binding plane by hydrogen-bonding side chains and 2) attractive van der Waal's interactions between the other residues of the ice-binding surface and the ice, which increases the strength of the protein-ice interaction.


  • Organizational Affiliation
    • Department of Biochemistry, Queen's University, Kingston, Ontario, K7L 3N6 Canada.

Macromolecule Content

  • Total Structure Weight: 6.95 kDa
  • Atom Count: 539
  • Modeled Residue Count: 66
  • Deposited Residue Count: 66
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
PROTEIN (ANTIFREEZE PROTEIN TYPE III)66Zoarces americanusMutation(s): 3
UniProt
Find proteins for P19614 (Zoarces americanus)
Explore P19614
Go to UniProtKB:  P19614
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP19614
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.05 Å
  • R-Value Free:  0.238 (Depositor)
  • R-Value Work:  0.172 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 32.71α = 90
b = 39.365β = 90
c = 46.511γ = 90
Software Package:
Software NamePurpose
X-PLORmodel building
X-PLORrefinement
DENZOdata reduction
SCALEPACKdata scaling
X-PLORphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1999-04-29
    Type: Initial release
  • Version 1.1: 2008-04-26
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2021-11-03
    Changes: Database references
  • Version 1.4: 2023-09-13
    Changes: Data collection, Refinement description
