3SGG

Crystal structure of a putative hydrolase (BT_2193) from Bacteroides thetaiotaomicron VPI-5482 at 1.25 A resolution

PDB DOI: https://doi.org/10.2210/pdb3SGG/pdb

Classification: HYDROLASE
Organism(s): Bacteroides thetaiotaomicron
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2011-06-14 Released: 2011-06-29
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.25 Å
R-Value Free: 0.176
R-Value Work: 0.151
R-Value Observed: 0.152

wwPDB Validation 3D Report Full Report

This is version 1.6 of the entry. See complete history.

Literature

Crystal structure of a Hypothetical hydrolase (BT_2193) from Bacteroides thetaiotaomicron VPI-5482 at 1.25 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 60.55 kDa
Atom Count: 4,982
Modelled Residue Count: 512
Deposited Residue Count: 536
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hypothetical hydrolase	A	536	Bacteroides thetaiotaomicron	Mutation(s): 0 Gene Names: BT_2193
UniProt
Find proteins for Q8A5P5 (Bacteroides thetaiotaomicron (strain ATCC 29148 / DSM 2079 / JCM 5827 / CCUG 10774 / NCTC 10582 / VPI-5482 / E50)) Explore Q8A5P5 Go to UniProtKB: Q8A5P5
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q8A5P5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] MOL2 format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] mmCIF format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A]	B [auth A], C [auth A], D [auth A], E [auth A], F [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.25 Å
R-Value Free: 0.176
R-Value Work: 0.151
R-Value Observed: 0.152
Space Group: C 1 2 1
Diffraction Data: https://doi.org/10.18430/M33SGG

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 161.915	α = 90
b = 49.37	β = 114.45
c = 71.359	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SHELX	phasing
SHARP	phasing
XSCALE	data scaling
REFMAC	refinement
XDS	data reduction
SHELXD	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2011-06-29

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2011-06-29
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2011-11-23
Changes: Structure summary
Version 1.3: 2014-12-24
Changes: Structure summary
Version 1.4: 2017-11-08
Changes: Refinement description
Version 1.5: 2023-02-01
Changes: Database references, Derived calculations
Version 1.6: 2024-11-20
Changes: Data collection, Structure summary
