3OTK | pdb_00003otk

Structure and mechanisim of core 2 beta1,6-n-acetylglucosaminyltransferase: a Metal-ion independent gt-a glycosyltransferase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:
    0.219 (Depositor), 0.222 (DCC)
  • R-Value Work:
    0.165 (Depositor)
  • R-Value Observed:
    0.168 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3OTK

Ligand Structure Quality Assessment


This is version 2.1 of the entry. See complete history

Literature

Structural and mechanistic characterization of leukocyte-type core 2 beta 1,6-N-acetylglucosaminyltransferase: a metal-ion-independent GT-A glycosyltransferase.

Pak, J.E.Satkunarajah, M.Seetharaman, J.Rini, J.M.

(2011) J Mol Biology 414: 798-811

  • DOI: https://doi.org/10.1016/j.jmb.2011.10.039
  • Primary Citation Related Structures:
    3OTK

  • PubMed Abstract:

    Leukocyte-type core 2 β1,6-N-acetylglucosaminyltransferase (C2GnT-L) is an inverting, metal-ion-independent glycosyltransferase that catalyzes the formation of mucin-type core 2 O-glycans. C2GnT-L belongs to the GT-A fold, yet it lacks the metal ion binding DXD motif characteristic of other nucleoside disphosphate GT-A fold glycosyltransferases. To shed light on the basis for its metal ion independence, we have solved the X-ray crystal structure (2.3 Å resolution) of a mutant form of C2GnT-L (C217S) in complex with the nucleotide sugar product UDP and, using site-directed mutagenesis, examined the roles of R378 and K401 in both substrate binding and catalysis. The structure shows that C2GnT-L exists in an "open" conformation and a "closed" conformation and that, in the latter, R378 and K401 interact with the β-phosphate moiety of the bound UDP. The two conformations are likely to be important in catalysis, but the conformational changes that lead to their interconversion do not resemble the nucleotide-sugar-mediated loop ordering observed in other GT-A glycosyltransferases. R378 and K401 were found to be important in substrate binding and/or catalysis, an observation consistent with the suggestion that they serve the same role played by metal ion in all of the other GT-A glycosyltransferases studied to date. Notably, R378 and K401 appear to function in a manner similar to that of the arginine and lysine residues contained in the RX(4-5)K motif found in the retaining GT-B glycosyltransferases.


  • Organizational Affiliation
    • Department of Molecular Genetics, University of Toronto, Toronto, Ontario, Canada M5S 1A8.

Macromolecule Content

  • Total Structure Weight: 185.2 kDa
  • Atom Count: 12,658
  • Modeled Residue Count: 1,456
  • Deposited Residue Count: 1,564
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Beta-1,3-galactosyl-O-glycosyl-glycoprotein beta-1,6-N-acetylglucosaminyltransferase
A, B, C, D
391Mus musculusMutation(s): 1
Gene Names: Gcnt1
EC: 2.4.1.102
UniProt & NIH Common Fund Data Resources
Find proteins for Q09324 (Mus musculus)
Explore Q09324
Go to UniProtKB:  Q09324
IMPC:  MGI:95676
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ09324
Glycosylation
Glycosylation Sites: 1Go to GlyGen: Q09324-1
Sequence Annotations
Expand
Reference Sequence

Oligosaccharides

Help
Entity ID: 2
MoleculeChains Length2D Diagram GlycosylationD Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-[alpha-L-fucopyranose-(1-6)]2-acetamido-2-deoxy-beta-D-glucopyranose
E, F
3N-Glycosylation
Glycosylation Resources
GlyTouCan: G21290RB
GlyCosmos: G21290RB
GlyGen: G21290RB

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
UDP

Query on UDP



Download:Ideal Coordinates CCD File
K [auth A],
M [auth B],
P [auth C],
R [auth D]
URIDINE-5'-DIPHOSPHATE
C9 H14 N2 O12 P2
XCCTYIAWTASOJW-XVFCMESISA-N
NAG

Query on NAG



Download:Ideal Coordinates CCD File
J [auth A],
L [auth B],
O [auth C],
Q [auth D]
2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
HTO

Query on HTO



Download:Ideal Coordinates CCD File
G [auth A],
H [auth A]
HEPTANE-1,2,3-TRIOL
C7 H16 O3
HXYCHJFUBNTKQR-RNFRBKRXSA-N
NA

Query on NA



Download:Ideal Coordinates CCD File
I [auth A],
N [auth C]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:  0.219 (Depositor), 0.222 (DCC)
  • R-Value Work:  0.165 (Depositor)
  • R-Value Observed: 0.168 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 73.874α = 90
b = 101.02β = 93.42
c = 136.612γ = 90
Software Package:
Software NamePurpose
ADSCdata collection
PHASERphasing
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2011-09-14
    Type: Initial release
  • Version 1.1: 2013-10-02
    Changes: Database references
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Database references, Derived calculations, Structure summary
  • Version 2.1: 2024-11-20
    Changes: Data collection, Database references, Structure summary
