Crystal structure of an anti-ECFsigma factor, ChrR (Maqu_0586) from Marinobacter aquaeolei VT8 at 1.70 A resolution
Joint Center for Structural Genomics (JCSG)To be published.
Experimental Data Snapshot
wwPDB Validation   3D Report Full Report
Entity ID: 1 | |||||
---|---|---|---|---|---|
Molecule | Chains | Sequence Length | Organism | Details | Image |
Anti-ECFsigma factor, ChrR | 223 | Marinobacter nauticus VT8 | Mutation(s): 0  Gene Names: Maqu_0586 | ||
UniProt | |||||
Find proteins for A1TY68 (Marinobacter nauticus (strain ATCC 700491 / DSM 11845 / VT8)) Explore A1TY68  Go to UniProtKB:  A1TY68 | |||||
Entity Groups   | |||||
Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
UniProt Group | A1TY68 | ||||
Sequence AnnotationsExpand | |||||
|
Ligands 4 Unique | |||||
---|---|---|---|---|---|
ID | Chains | Name / Formula / InChI Key | 2D Diagram | 3D Interactions | |
NIO Query on NIO | D [auth A] | NICOTINIC ACID C6 H5 N O2 PVNIIMVLHYAWGP-UHFFFAOYSA-N | |||
SO4 Query on SO4 | E [auth A], F [auth A], Q [auth B], R [auth B], S [auth B] | SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L | |||
ZN Query on ZN | C [auth A], P [auth B] | ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N | |||
EDO Query on EDO | G [auth A] H [auth A] I [auth A] J [auth A] K [auth A] | 1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N |
Modified Residues 1 Unique | |||||
---|---|---|---|---|---|
ID | Chains | Type | Formula | 2D Diagram | Parent |
MSE Query on MSE | A, B | L-PEPTIDE LINKING | C5 H11 N O2 Se | MET |
Length ( Å ) | Angle ( ˚ ) |
---|---|
a = 44.105 | α = 75.96 |
b = 45.773 | β = 71.08 |
c = 65.892 | γ = 63.35 |
Software Name | Purpose |
---|---|
SHELX | phasing |
REFMAC | refinement |
SCALA | data scaling |
PDB_EXTRACT | data extraction |
MOSFLM | data reduction |
SHELXD | phasing |
autoSHARP | phasing |
