3MCX | pdb_00003mcx

Crystal structure of SusD superfamily protein (BT_2365) from BACTEROIDES THETAIOTAOMICRON VPI-5482 at 1.49 A resolution

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.49 Å
  • R-Value Free:
    0.161 (Depositor), 0.178 (DCC)
  • R-Value Work:
    0.142 (Depositor)
  • R-Value Observed:
    0.143 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3MCX

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of SusD superfamily protein (BT_2365) from BACTEROIDES THETAIOTAOMICRON VPI-5482 at 1.49 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

  • Total Structure Weight: 54.68 kDa
  • Atom Count: 4,583
  • Modeled Residue Count: 459
  • Deposited Residue Count: 477
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:
|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
SusD superfamily protein477Bacteroides thetaiotaomicron VPI-5482Mutation(s): 0
Gene Names: BT_2365
UniProt
Find proteins for Q8A577 (Bacteroides thetaiotaomicron (strain ATCC 29148 / DSM 2079 / JCM 5827 / CCUG 10774 / NCTC 10582 / VPI-5482 / E50))
Explore Q8A577
Go to UniProtKB:  Q8A577
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8A577
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
GOL

Query on GOL


Download:Ideal Coordinates CCD File
K [auth A],
L [auth A],
M [auth A],
N [auth A],
O [auth A]		GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
ZN

Query on ZN


Download:Ideal Coordinates CCD File
B [auth A]
C [auth A]
D [auth A]
E [auth A]
F [auth A]
B [auth A],
C [auth A],
D [auth A],
E [auth A],
F [auth A],
G [auth A]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
ACT

Query on ACT


Download:Ideal Coordinates CCD File
H [auth A],
I [auth A],
J [auth A]		ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A
L-PEPTIDE LINKINGC5 H11 N O2 SeMET

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.49 Å
  • R-Value Free:  0.161 (Depositor), 0.178 (DCC)
  • R-Value Work:  0.142 (Depositor)
  • R-Value Observed: 0.143 (Depositor)
Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 107.161α = 90
b = 147.472β = 90
c = 73.434γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PHENIXrefinement
SHELXphasing
MolProbitymodel building
XSCALEdata scaling
PDB_EXTRACTdata extraction
XDSdata reduction
SHELXDphasing
autoSHARPphasing

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-05-19
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Advisory, Version format compliance
  • Version 1.2: 2017-10-25
    Changes: Author supporting evidence, Refinement description
  • Version 1.3: 2019-07-17
    Changes: Data collection, Derived calculations, Refinement description
  • Version 1.4: 2023-02-01
    Changes: Database references, Derived calculations
  • Version 1.5: 2024-10-09
    Changes: Data collection, Structure summary
