3LZA | pdb_00003lza

Crystal structure of Putative SnoaL-like polyketide cyclase (YP_563807.1) from SHEWANELLA DENITRIFICANS OS-217 at 1.70 A resolution

PDB DOI: https://doi.org/10.2210/pdb3LZA/pdb

Classification: LYASE
Organism(s): Shewanella denitrificans OS217
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2010-03-01 Released: 2010-05-12
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.238 (Depositor), 0.248 (DCC)
R-Value Work:
0.193 (Depositor), 0.209 (DCC)
R-Value Observed:
0.195 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3LZA

This is version 1.5 of the entry. See complete history.

Literature

CRYSTAL STRUCTURE OF PUTATIVE SNOAL-LIKE POLYKETIDE CYCLASE (YP_563807.1) FROM SHEWANELLA DENITRIFICANS OS-217 AT 1.70 A RESOLUTION

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 65.19 kDa
Atom Count: 5,149
Modeled Residue Count: 547
Deposited Residue Count: 564
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative SnoaL-like polyketide cyclase	A, B, C, D	141	Shewanella denitrificans OS217	Mutation(s): 0 Gene Names: YP_563807.1, Sden_2805
UniProt
Find proteins for Q12KE2 (Shewanella denitrificans (strain OS217 / ATCC BAA-1090 / DSM 15013)) Explore Q12KE2 Go to UniProtKB: Q12KE2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q12KE2
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B, C, D	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.238 (Depositor), 0.248 (DCC)
R-Value Work: 0.193 (Depositor), 0.209 (DCC)
R-Value Observed: 0.195 (Depositor)

Diffraction Data:

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 45.843	α = 90.13
b = 56.51	β = 103.27
c = 57.537	γ = 102.85

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SOLVE	phasing
MolProbity	model building
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-05-12

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2010-05-12
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.2: 2017-11-08
Changes: Refinement description
Version 1.3: 2019-07-17
Changes: Data collection, Derived calculations, Refinement description
Version 1.4: 2023-02-01
Changes: Database references
Version 1.5: 2024-11-27
Changes: Data collection, Structure summary
