3CEX | pdb_00003cex

Crystal structure of the conserved protein of locus EF_3021 from Enterococcus faecalis

• PDB DOI: https://doi.org/10.2210/pdb3CEX/pdb

• Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
• Organism(s): Enterococcus faecalis V583
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2008-02-29 Released: 2008-05-13
• Deposition Author(s): Cuff, M.E., Wu, R., Moy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:
  0.205 (Depositor), 0.210 (DCC)
• R-Value Work:
  0.162 (Depositor), 0.169 (DCC)
• R-Value Observed:
  0.164 (Depositor)

Literature

Structure of the conserved protein of locus EF_3021 from Enterococcus faecalis.

Cuff, M.E., Wu, R., Moy, S., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 generated by PISA (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 39.88 kDa
• Atom Count: 2,970
• Modeled Residue Count: 340
• Deposited Residue Count: 344
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized protein	A, B	172	Enterococcus faecalis V583	Mutation(s): 0  Gene Names: EF_3021
UniProt
Find proteins for Q82ZN0 (Enterococcus faecalis (strain ATCC 700802 / V583)) Explore Q82ZN0  Go to UniProtKB:  Q82ZN0

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	D [auth A], F [auth B]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
ACY	C [auth A], E [auth B]	ACETIC ACID C2 H4 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:  0.205 (Depositor), 0.210 (DCC)
• R-Value Work:  0.162 (Depositor), 0.169 (DCC)
• R-Value Observed: 0.164 (Depositor)

Space Group: P 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 55.191	α = 90
b = 55.137	β = 108.2
c = 62.429	γ = 90

Software Package:

Software Name	Purpose
MLPHARE	phasing
DM	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
SBC-Collect	data collection
DENZO	data reduction
HKL-3000	data scaling
HKL-3000	phasing
SHELXD	phasing
SHELXE	model building
SOLVE	phasing
RESOLVE	phasing
ARP/wARP	model building
CCP4	phasing
O	model building
Coot	model building

Structure Validation

Entry History

Deposition Data

• Released Date: 2008-05-13
Deposition Author(s): Cuff, M.E., Wu, R., Moy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2008-05-13
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Source and taxonomy, Version format compliance
• Version 1.2: 2024-11-06
  Changes: Data collection, Database references, Derived calculations, Structure summary
