3WS6 | pdb_00003ws6

Crystal Structure of H-2D in complex with a mimotopic peptide


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.98 Å
  • R-Value Free:
    0.224 (Depositor), 0.224 (DCC)
  • R-Value Work:
    0.169 (Depositor), 0.172 (DCC)
  • R-Value Observed:
    0.172 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3WS6

This is version 1.6 of the entry. See complete history

Literature

Compensatory mechanisms allow undersized anchor-deficient class I MHC ligands to mediate pathogenic autoreactive T cell responses

Lamont, D.Mukherjee, G.Kumar, P.R.Samanta, D.McPhee, C.G.Kay, T.W.H.Almo, S.C.DiLorenzo, T.P.Serreze, D.V.

(2014) J Immunol 193: 2135-2146

  • DOI: https://doi.org/10.4049/jimmunol.1400997
  • Primary Citation Related Structures:
    3WS3, 3WS6

  • PubMed Abstract:

    Self-reactive T cells must escape thymic negative selection to mediate pathogenic autoimmunity. In the NOD mouse model of autoimmune diabetes, several β cell-cytotoxic CD8 T cell populations are known, with the most aggressive of these represented by AI4, a T cell clone with promiscuous Ag-recognition characteristics. We identified a long-elusive β cell-specific ligand for AI4 as an unusually short H-2D(b)-binding 7-mer peptide lacking a C-terminal anchor residue and derived from the insulin A chain (InsA14-20). Crystallography reveals that compensatory mechanisms permit peptides lacking a C-terminal anchor to bind sufficiently to the MHC to enable destructive T cell responses, yet allow cognate T cells to avoid negative selection. InsA14-20 shares two solvent-exposed residues with previously identified AI4 ligands, providing a structural explanation for AI4's promiscuity. Detection of AI4-like T cells, using mimotopes of InsA14-20 with improved H-2D(b)-binding characteristics, establishes the AI4-like T cell population as a consistent feature of the islet infiltrates of NOD mice. Our work establishes undersized peptides as previously unrecognized targets of autoreactive CD8 T cells and presents a strategy for their further exploration as Ags in autoimmune disease.


  • Organizational Affiliation
    • The Jackson Laboratory, Bar Harbor, ME 04609;

Macromolecule Content

  • Total Structure Weight: 91.32 kDa
  • Atom Count: 6,973
  • Modeled Residue Count: 755
  • Deposited Residue Count: 768
  • Unique protein chains: 3

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
H-2 class I histocompatibility antigen, D-B alpha chainA,
C [auth B]
275Mus musculusMutation(s): 0
Gene Names: H-2DbH2-D1
UniProt
Find proteins for P01899 (Mus musculus)
Explore P01899
Go to UniProtKB:  P01899
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP01899
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Beta-2-microglobulinB [auth D],
D [auth C]
100Mus musculusMutation(s): 0
Gene Names: B2m
UniProt & NIH Common Fund Data Resources
Find proteins for P01887 (Mus musculus)
Explore P01887
Go to UniProtKB:  P01887
IMPC:  MGI:88127
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP01887
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:  Sequence   |   3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Mimotope 9-mer peptide
E, F
9N/AMutation(s): 0

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SO4

Query on SO4



Download:Ideal Coordinates CCD File
L [auth D],
U [auth C],
V [auth C]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL

Query on GOL



Download:Ideal Coordinates CCD File
J [auth A],
Q [auth B],
R [auth B],
S [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
IMD

Query on IMD



Download:Ideal Coordinates CCD File
H [auth A]
I [auth A]
M [auth D]
O [auth B]
P [auth B]
H [auth A],
I [auth A],
M [auth D],
O [auth B],
P [auth B],
W [auth C]
IMIDAZOLE
C3 H5 N2
RAXXELZNTBOGNW-UHFFFAOYSA-O
ZN

Query on ZN



Download:Ideal Coordinates CCD File
G [auth A],
K [auth D],
N [auth B],
T [auth C]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.98 Å
  • R-Value Free:  0.224 (Depositor), 0.224 (DCC)
  • R-Value Work:  0.169 (Depositor), 0.172 (DCC)
  • R-Value Observed: 0.172 (Depositor)
Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 162.723α = 90
b = 69.265β = 90
c = 73.753γ = 90
Software Package:
Software NamePurpose
SCALEPACKdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
HKL-3000data reduction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2014-03-26
    Type: Initial release
  • Version 1.1: 2018-01-24
    Changes: Structure summary
  • Version 1.2: 2018-02-07
    Changes: Database references, Structure summary
  • Version 1.3: 2023-11-08
    Changes: Data collection, Database references, Derived calculations, Refinement description
  • Version 1.4: 2024-10-30
    Changes: Structure summary
  • Version 1.5: 2025-10-15
    Changes: Structure summary
  • Version 1.6: 2025-10-22
    Changes: Structure summary
