3WKP | pdb_00003wkp

C135A mutant of Geobacillus thermodenitrificans copper-containing nitrite reductase in complex with nitrite

PDB DOI: https://doi.org/10.2210/pdb3WKP/pdb

Classification: OXIDOREDUCTASE
Organism(s): Geobacillus thermodenitrificans NG80-2
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2013-10-29 Released: 2013-12-11
Deposition Author(s): Fukuda, Y., Inoue, T.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.206 (Depositor), 0.207 (DCC)
R-Value Work:
0.156 (Depositor), 0.158 (DCC)
R-Value Observed:
0.159 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3WKP

This is version 1.1 of the entry. See complete history.

Literature

C135A mutant of Geobacillus thermodenitrificans copper-containing nitrite reductase in complex with nitrite

Fukuda, Y., Inoue, T.

To be published.

Macromolecule Content

Total Structure Weight: 36.02 kDa
Atom Count: 2,627
Modeled Residue Count: 295
Deposited Residue Count: 323
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Nitrite reductase	A	323	Geobacillus thermodenitrificans NG80-2	Mutation(s): 1 Gene Names: nirK EC: 1.7.2.1
UniProt
Find proteins for A4IL26 (Geobacillus thermodenitrificans (strain NG80-2)) Explore A4IL26 Go to UniProtKB: A4IL26
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A4IL26
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MPD Query on MPD Download:Ideal Coordinates CCD File SDF format, chain G [auth A] MOL2 format, chain G [auth A] mmCIF format, chain G [auth A]	G [auth A]	(4S)-2-METHYL-2,4-PENTANEDIOL C₆ H₁₄ O₂ SVTBMSDMJJWYQN-YFKPBYRVSA-N		Interactions Focus chain G [auth A] Interactions & Density Focus chain G [auth A]
PEG Query on PEG Download:Ideal Coordinates CCD File SDF format, chain H [auth A] MOL2 format, chain H [auth A] mmCIF format, chain H [auth A]	H [auth A]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Interactions & Density Focus chain H [auth A]
CU Query on CU Download:Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] MOL2 format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] mmCIF format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A]	B [auth A], C [auth A], D [auth A], E [auth A]	COPPER (II) ION Cu JPVYNHNXODAKFH-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A]
NO2 Query on NO2 Download:Ideal Coordinates CCD File SDF format, chain F [auth A] MOL2 format, chain F [auth A] mmCIF format, chain F [auth A]	F [auth A]	NITRITE ION N O₂ IOVCWXUNBOPUCH-UHFFFAOYSA-M		Interactions Focus chain F [auth A] Interactions & Density Focus chain F [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.206 (Depositor), 0.207 (DCC)
R-Value Work: 0.156 (Depositor), 0.158 (DCC)
R-Value Observed: 0.159 (Depositor)

Space Group: H 3

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 114.866	α = 90
b = 114.866	β = 90
c = 84.039	γ = 120

Software Package:

Software Name	Purpose
BSS	data collection
MOLREP	phasing
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2013-12-11

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2013-12-11
Type: Initial release
Version 1.1: 2024-03-20
Changes: Data collection, Database references, Derived calculations
