3UF6

The crystal structure of a possible phosphate acetyl/butaryl transferase (from Listeria monocytogenes EGD-e) in complex with CoD (3'-dephosphocoenzyme A)

• PDB DOI: https://doi.org/10.2210/pdb3UF6/pdb

• Classification: TRANSFERASE
• Organism(s): Listeria monocytogenes EGD-e
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2011-10-31 Released: 2011-11-16
• Deposition Author(s): Tan, K., Zhou, M., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:
  0.209 (Depositor), 0.200 (DCC)
• R-Value Work:
  0.164 (Depositor), 0.160 (DCC)
• R-Value Observed:
  0.166 (Depositor)

Starting Model: experimental

Literature

The crystal structure of a possible phosphate acetyl/butaryl transferase (from Listeria monocytogenes EGD-e) in complex with CoD (3'-dephosphocoenzyme A)

Tan, K., Zhou, M., Kwon, K., Anderson, W.F., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 63.92 kDa
• Atom Count: 4,767
• Modelled Residue Count: 571
• Deposited Residue Count: 582
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lmo1369 protein	A, B	291	Listeria monocytogenes EGD-e	Mutation(s): 0  Gene Names: lmo1369
UniProt
Find proteins for Q8Y7B7 (Listeria monocytogenes serovar 1/2a (strain ATCC BAA-679 / EGD-e)) Explore Q8Y7B7  Go to UniProtKB:  Q8Y7B7

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
COD	C [auth A], D [auth B]	DEPHOSPHO COENZYME A C21 H35 N7 O13 P2 S KDTSHFARGAKYJN-IBOSZNHHSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:  0.209 (Depositor), 0.200 (DCC)
• R-Value Work:  0.164 (Depositor), 0.160 (DCC)
• R-Value Observed: 0.166 (Depositor)

Diffraction Data: https://doi.org/10.18430/m33uf6

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.44	α = 90
b = 75.594	β = 91.62
c = 60.332	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
MOLREP	phasing
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2011-11-16
Deposition Author(s): Tan, K., Zhou, M., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History

• Version 1.0: 2011-11-16
  Type: Initial release

• Version 1.1: 2023-09-13
  Changes: Data collection, Database references, Derived calculations, Refinement description
• Version 1.2: 2023-12-06
  Changes: Data collection
• Version 1.3: 2024-11-20
  Changes: Structure summary
