3TWK | pdb_00003twk

Crystal structure of arabidopsis thaliana FPG


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:
    0.273 (Depositor), 0.281 (DCC)
  • R-Value Work:
    0.222 (Depositor), 0.231 (DCC)

wwPDB Validation 3D Report Full Report

Validation slider image for 3TWK

This is version 1.2 of the entry. See complete history

Literature

Structural and biochemical studies of a plant formamidopyrimidine-DNA glycosylase reveal why eukaryotic Fpg glycosylases do not excise 8-oxoguanine.

Duclos, S.Aller, P.Jaruga, P.Dizdaroglu, M.Wallace, S.S.Doublie, S.

(2012) DNA Repair (Amst) 11: 714-725

  • DOI: https://doi.org/10.1016/j.dnarep.2012.06.004
  • Primary Citation Related Structures:
    3TWK, 3TWL, 3TWM

  • PubMed Abstract:

    Formamidopyrimidine-DNA glycosylase (Fpg; MutM) is a DNA repair enzyme widely distributed in bacteria. Fpg recognizes and excises oxidatively modified purines, 4,6-diamino-5-formamidopyrimidine, 2,6-diamino-4-hydroxy-5-formamidopyrimidine and 8-oxoguanine (8-oxoG), with similar excision kinetics. It exhibits some lesser activity toward 8-oxoadenine. Fpg enzymes are also present in some plant and fungal species. The eukaryotic Fpg homologs exhibit little or no activity on DNA containing 8-oxoG, but they recognize and process its oxidation products, guanidinohydantoin (Gh) and spiroiminohydantoin (Sp). To date, several structures of bacterial Fpg enzymes unliganded or in complex with DNA containing a damaged base have been published but there is no structure of a eukaryotic Fpg. Here we describe the first crystal structure of a plant Fpg, Arabidopsis thaliana (AthFpg), unliganded and bound to DNA containing an abasic site analog, tetrahydrofuran (THF). Although AthFpg shares a common architecture with other Fpg glycosylases, it harbors a zincless finger, previously described in a subset of Nei enzymes, such as human NEIL1 and Mimivirus Nei1. Importantly the "αF-β9/10 loop" capping 8-oxoG in the active site of bacterial Fpg is very short in AthFpg. Deletion of a segment encompassing residues 213-229 in Escherichia coli Fpg (EcoFpg) and corresponding to the "αF-β9/10 loop" does not affect the recognition and removal of oxidatively damaged DNA base lesions, with the exception of 8-oxoG. Although the exact role of the loop remains to be further explored, it is now clear that this protein segment is specific to the processing of 8-oxoG.


  • Organizational Affiliation
    • Department of Microbiology and Molecular Genetics, The Markey Center for Molecular Genetics, University of Vermont, Stafford Hall, Burlington, VT 05405-0068, USA. swallace@uvm.edu

Macromolecule Content

  • Total Structure Weight: 66.93 kDa
  • Atom Count: 4,843
  • Modeled Residue Count: 579
  • Deposited Residue Count: 594
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Formamidopyrimidine-DNA glycosylase 1
A, B
297Arabidopsis thalianaMutation(s): 0
Gene Names: fpg1
EC: 3.2.2.23 (PDB Primary Data), 4.2.99.18 (UniProt)
UniProt
Find proteins for O80358 (Arabidopsis thaliana)
Explore O80358
Go to UniProtKB:  O80358
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO80358
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, B
L-PEPTIDE LINKINGC5 H11 N O2 SeMET

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:  0.273 (Depositor), 0.281 (DCC)
  • R-Value Work:  0.222 (Depositor), 0.231 (DCC)
Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 93.054α = 90
b = 93.054β = 90
c = 157.7γ = 90
Software Package:
Software NamePurpose
SHARPphasing
SOLOMONphasing
CNSrefinement
PDB_EXTRACTdata extraction
HKL-2000data collection
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-07-25
    Type: Initial release
  • Version 1.1: 2012-08-29
    Changes: Database references
  • Version 1.2: 2024-10-09
    Changes: Data collection, Database references, Derived calculations, Structure summary
