3S52 | pdb_00003s52

Crystal structure of a putative fumarylacetoacetate hydrolase family protein from Yersinia pestis CO92

• PDB DOI: https://doi.org/10.2210/pdb3S52/pdb

• Classification: HYDROLASE
• Organism(s): Yersinia pestis CO92
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2011-05-20 Released: 2011-06-29
• Deposition Author(s): Nocek, B., Zhou, M., Grimshaw, S., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.01 Å
• R-Value Free:
  0.211 (Depositor), 0.208 (DCC)
• R-Value Work:
  0.160 (Depositor), 0.165 (DCC)
• R-Value Observed:
  0.163 (Depositor)

Literature

Crystal structure of a putative fumarylacetoacetate hydrolase family protein from Yersinia pestis CO92

Nocek, B., Zhou, M., Grimshaw, S., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 98.04 kDa
• Atom Count: 7,146
• Modeled Residue Count: 854
• Deposited Residue Count: 884
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative fumarylacetoacetate hydrolase family protein	A, B, C, D	221	Yersinia pestis CO92	Mutation(s): 0  Gene Names: y2229
UniProt
Find proteins for Q8D0F9 (Yersinia pestis) Explore Q8D0F9  Go to UniProtKB:  Q8D0F9

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	E [auth A], F [auth A], G [auth B], H [auth C], I [auth D]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
CL	J [auth D]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B, C, D	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.01 Å
• R-Value Free:  0.211 (Depositor), 0.208 (DCC)
• R-Value Work:  0.160 (Depositor), 0.165 (DCC)
• R-Value Observed: 0.163 (Depositor)

Diffraction Data: https://doi.org/10.18430/m33s52

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 61.169	α = 90
b = 92.143	β = 90
c = 157.95	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
HKL-3000	phasing
SHELX	model building
ARP/wARP	model building
MOLREP	phasing
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
SHELX	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2011-06-29
Deposition Author(s): Nocek, B., Zhou, M., Grimshaw, S., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History

• Version 1.0: 2011-06-29
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2024-11-06
  Changes: Data collection, Database references, Derived calculations, Structure summary
