3QTA | pdb_00003qta

Crystal structure of a CheC-like protein (rrnAC0528) from Haloarcula marismortui ATCC 43049 at 2.00 A resolution

PDB DOI: https://doi.org/10.2210/pdb3QTA/pdb

Classification: ATTRACTANT
Organism(s): Haloarcula marismortui ATCC 43049
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2011-02-22 Released: 2011-04-06
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.202 (Depositor), 0.210 (DCC)
R-Value Work:
0.175 (Depositor), 0.182 (DCC)
R-Value Observed:
0.176 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3QTA

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of a Hypothetical CheC-like protein (rrnAC0528) from HALOARCULA MARISMORTUI ATCC 43049 at 2.00 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 51.39 kDa
Atom Count: 3,579
Modeled Residue Count: 406
Deposited Residue Count: 466
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Chemotaxis protein CheC	A, B	233	Haloarcula marismortui ATCC 43049	Mutation(s): 0 Gene Names: cheC1, rrnAC0528
UniProt
Find proteins for Q5V4K4 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809)) Explore Q5V4K4 Go to UniProtKB: Q5V4K4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q5V4K4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain I [auth B] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain I [auth B] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain I [auth B]	E [auth A], F [auth A], G [auth A], I [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth B] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth B]
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain H [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain H [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain H [auth B]	C [auth A], D [auth A], H [auth B]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain H [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain H [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.202 (Depositor), 0.210 (DCC)
R-Value Work: 0.175 (Depositor), 0.182 (DCC)
R-Value Observed: 0.176 (Depositor)

Diffraction Data:

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 89.928	α = 90
b = 89.928	β = 90
c = 148.299	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SOLVE	phasing
SCALA	data scaling
MOSFLM	data reduction
REFMAC	refinement

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2011-04-06

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2011-04-06
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2014-12-24
Changes: Structure summary
Version 1.3: 2017-11-08
Changes: Refinement description
Version 1.4: 2023-02-01
Changes: Database references, Derived calculations
Version 1.5: 2024-10-30
Changes: Data collection, Structure summary
