3QAN | pdb_00003qan

Crystal structure of 1-pyrroline-5-carboxylate dehydrogenase from bacillus halodurans

PDB DOI: https://doi.org/10.2210/pdb3QAN/pdb

Classification: OXIDOREDUCTASE
Organism(s): Halalkalibacterium halodurans
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2011-01-11 Released: 2011-02-02
Deposition Author(s): Patskovsky, Y., Toro, R., Foti, R., Seidel, R.D., Almo, S.C., New York Structural Genomics Research Consortium (NYSGRC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.95 Å
R-Value Free:
0.280 (Depositor), 0.279 (DCC)
R-Value Work:
0.216 (Depositor), 0.217 (DCC)
R-Value Observed:
0.218 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3QAN

This is version 1.2 of the entry. See complete history.

Literature

Crystal Structure of 1-Pyrroline-5-Carboxylate Dehydrogenase from Bacillus Halodurans

Patskovsky, Y., Toro, R., Foti, R., Seidel, R.D., Almo, S.C.

To be published.

Macromolecule Content

Total Structure Weight: 178.96 kDa
Atom Count: 12,781
Modeled Residue Count: 1,547
Deposited Residue Count: 1,614
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
1-pyrroline-5-carboxylate dehydrogenase 1	A, B, C	538	Halalkalibacterium halodurans	Mutation(s): 0 Gene Names: rocA1, BH2737 EC: 1.5.1.12 (PDB Primary Data), 1.2.1.88 (UniProt)
UniProt
Find proteins for Q9K9B2 (Halalkalibacterium halodurans (strain ATCC BAA-125 / DSM 18197 / FERM 7344 / JCM 9153 / C-125)) Explore Q9K9B2 Go to UniProtKB: Q9K9B2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9K9B2
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ACT Query on ACT Download:Ideal Coordinates CCD File SDF format, chain D [auth C] MOL2 format, chain D [auth C] mmCIF format, chain D [auth C]	D [auth C]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain D [auth C] Interactions & Density Focus chain D [auth C]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.95 Å
R-Value Free: 0.280 (Depositor), 0.279 (DCC)
R-Value Work: 0.216 (Depositor), 0.217 (DCC)
R-Value Observed: 0.218 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 101.897	α = 90
b = 75.559	β = 98.48
c = 217.39	γ = 90

Software Package:

Software Name	Purpose
PHASER	phasing
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2011-02-02

Deposition Author(s):

New York Structural Genomics Research Consortium (NYSGRC)

Revision History (Full details and data files)

Version 1.0: 2011-02-02
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2023-09-13
Changes: Data collection, Database references, Derived calculations, Refinement description
