3P6L | pdb_00003p6l

Crystal structure of a Sugar phosphate isomerase/epimerase (BDI_1903) from Parabacteroides distasonis ATCC 8503 at 1.85 A resolution

PDB DOI: https://doi.org/10.2210/pdb3P6L/pdb

Classification: ISOMERASE
Organism(s): Parabacteroides distasonis ATCC 8503
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2010-10-11 Released: 2010-12-08
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free:
0.238 (Depositor), 0.239 (DCC)
R-Value Work:
0.186 (Depositor), 0.193 (DCC)
R-Value Observed:
0.189 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3P6L

This is version 1.4 of the entry. See complete history.

Literature

Crystal structure of a Sugar phosphate isomerase/epimerase (BDI_1903) from Parabacteroides distasonis ATCC 8503 at 1.85 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 30.68 kDa
Atom Count: 2,383
Modeled Residue Count: 262
Deposited Residue Count: 262
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Sugar phosphate isomerase/epimerase	A	262	Parabacteroides distasonis ATCC 8503	Mutation(s): 0 Gene Names: BDI_1903
UniProt
Find proteins for A6LD74 (Parabacteroides distasonis (strain ATCC 8503 / DSM 20701 / CIP 104284 / JCM 5825 / NCTC 11152)) Explore A6LD74 Go to UniProtKB: A6LD74
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A6LD74
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CIT Query on CIT Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	CITRIC ACID C₆ H₈ O₇ KRKNYBCHXYNGOX-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
PEG Query on PEG Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A], D [auth A]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A]
PO4 Query on PO4 Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free: 0.238 (Depositor), 0.239 (DCC)
R-Value Work: 0.186 (Depositor), 0.193 (DCC)
R-Value Observed: 0.189 (Depositor)

Diffraction Data:

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 82.382	α = 90
b = 73.014	β = 103.73
c = 47.536	γ = 90

Software Package:

Software Name	Purpose
SHELX	phasing
REFMAC	refinement
SCALA	data scaling
PDB_EXTRACT	data extraction
MOSFLM	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-12-08

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2010-12-08
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2011-07-20
Changes: Structure summary
Version 1.3: 2023-02-01
Changes: Database references, Derived calculations
Version 1.4: 2024-11-20
Changes: Data collection, Structure summary
