3ON4 | pdb_00003on4

Crystal structure of TetR transcriptional regulator from Legionella pneumophila

• PDB DOI: https://doi.org/10.2210/pdb3ON4/pdb

• Classification: TRANSCRIPTION
• Organism(s): Legionella pneumophila subsp. pneumophila str. Philadelphia 1
• Expression System: Escherichia coli BL21
• Mutation(s): No


• Deposited: 2010-08-27 Released: 2010-09-22
• Deposition Author(s): Michalska, K., Li, H., Gu, M., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.85 Å
• R-Value Free:
  0.218 (Depositor), 0.230 (DCC)
• R-Value Work:
  0.179 (Depositor), 0.194 (DCC)
• R-Value Observed:
  0.179 (Depositor)

Literature

Crystal structure of TetR transcriptional regulator from Legionella pneumophila

Michalska, K., Li, H., Gu, M., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Biological Assembly 3

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 3 assigned by authors and generated by PISA (software)

Biological Assembly 4

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 4 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 171.48 kDa
• Atom Count: 12,866
• Modeled Residue Count: 1,499
• Deposited Residue Count: 1,528
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Transcriptional regulator, TetR family	A, B, C, D, E, F, G, H	191	Legionella pneumophila subsp. pneumophila str. Philadelphia 1	Mutation(s): 0  Gene Names: lpg1967
UniProt
Find proteins for Q5ZU41 (Legionella pneumophila subsp. pneumophila (strain Philadelphia 1 / ATCC 33152 / DSM 7513)) Explore Q5ZU41  Go to UniProtKB:  Q5ZU41

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PEG	J [auth B]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
NA	I [auth A], K [auth C], L [auth D], M [auth E]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B, C, D, E, F, G, H	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.85 Å
• R-Value Free:  0.218 (Depositor), 0.230 (DCC)
• R-Value Work:  0.179 (Depositor), 0.194 (DCC)
• R-Value Observed: 0.179 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 81.38	α = 90
b = 124.99	β = 90
c = 151.38	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
SHELX	model building
MLPHARE	phasing
DM	model building
ARP/wARP	model building
Coot	model building
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling
SHELX	phasing
DM	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2010-09-22
Deposition Author(s): Michalska, K., Li, H., Gu, M., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2010-09-22
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2024-11-06
  Changes: Data collection, Database references, Derived calculations, Structure summary
