3OG8 | pdb_00003og8

Crystal structure of human RIG-I CTD bound to a 14-bp blunt-ended dsRNA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free:
    0.278 (Depositor), 0.272 (DCC)
  • R-Value Work:
    0.217 (Depositor), 0.212 (DCC)
  • R-Value Observed:
    0.217 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3OG8

This is version 1.2 of the entry. See complete history

Literature

Crystal structure of RIG-I C-terminal domain bound to blunt-ended double-strand RNA without 5' triphosphate.

Lu, C.Ranjith-Kumar, C.T.Hao, L.Kao, C.C.Li, P.

(2011) Nucleic Acids Res 39: 1565-1575

  • DOI: https://doi.org/10.1093/nar/gkq974
  • Primary Citation Related Structures:
    3OG8

  • PubMed Abstract:

    RIG-I recognizes molecular patterns in viral RNA to regulate the induction of type I interferons. The C-terminal domain (CTD) of RIG-I exhibits high affinity for 5' triphosphate (ppp) dsRNA as well as blunt-ended dsRNA. Structures of RIG-I CTD bound to 5'-ppp dsRNA showed that RIG-I recognizes the termini of dsRNA and interacts with the ppp through electrostatic interactions. However, the structural basis for the recognition of non-phosphorylated dsRNA by RIG-I is not fully understood. Here, we show that RIG-I CTD binds blunt-ended dsRNA in a different orientation compared to 5' ppp dsRNA and interacts with both strands of the dsRNA. Overlapping sets of residues are involved in the recognition of blunt-ended dsRNA and 5' ppp dsRNA. Mutations at the RNA-binding surface affect RNA binding and signaling by RIG-I. These results provide the mechanistic basis for how RIG-I recognizes different RNA ligands.


  • Organizational Affiliation
    • Department of Biochemistry and Biophysics, Texas A&M University, College Station, TX 77843-2128, USA.

Macromolecule Content

  • Total Structure Weight: 39.24 kDa
  • Atom Count: 2,829
  • Modeled Residue Count: 282
  • Deposited Residue Count: 284
  • Unique protein chains: 1
  • Unique nucleic acid chains: 1

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Antiviral innate immune response receptor RIG-I
A, B
128Homo sapiensMutation(s): 1
Gene Names: RIGIDDX58
EC: 3.6.4.13
UniProt & NIH Common Fund Data Resources
Find proteins for O95786 (Homo sapiens)
Explore O95786
Go to UniProtKB:  O95786
PHAROS:  O95786
GTEx:  ENSG00000107201
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO95786
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
RNA (5'-R(*GP*GP*CP*GP*CP*GP*CP*GP*CP*GP*CP*GP*CP*C)-3')
C, D
14synthetic construct
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free:  0.278 (Depositor), 0.272 (DCC)
  • R-Value Work:  0.217 (Depositor), 0.212 (DCC)
  • R-Value Observed: 0.217 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 36.99α = 90
b = 70.3β = 90
c = 125.54γ = 90
Software Package:
Software NamePurpose
CrystalCleardata collection
MOLREPphasing
CNSrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

  • Released Date: 2010-11-03
  • Deposition Author(s): Li, P.

Revision History  (Full details and data files)

  • Version 1.0: 2010-11-03
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2024-02-21
    Changes: Data collection, Database references, Derived calculations, Source and taxonomy, Structure summary
