3NZE | pdb_00003nze

The crystal structure of a domain of a possible sugar-binding transcriptional regulator from Arthrobacter aurescens TC1.

PDB DOI: https://doi.org/10.2210/pdb3NZE/pdb

Classification: Transcription regulator
Organism(s): Paenarthrobacter aurescens TC1
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2010-07-16 Released: 2010-08-11
Deposition Author(s): Tan, K., Zhang, R., Bigelow, L., Buck, K., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.199 (Depositor), 0.195 (DCC)
R-Value Work:
0.168 (Depositor), 0.169 (DCC)
R-Value Observed:
0.170 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3NZE

This is version 1.2 of the entry. See complete history.

Literature

The crystal structure of a domain of a possible sugar-binding transcriptional regulator from Arthrobacter aurescens TC1.

Tan, K., Zhang, R., Bigelow, L., Buck, K., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 58.21 kDa
Atom Count: 4,379
Modeled Residue Count: 518
Deposited Residue Count: 534
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative transcriptional regulator, sugar-binding family	A, B	267	Paenarthrobacter aurescens TC1	Mutation(s): 0 Gene Names: AAur_2250
UniProt
Find proteins for A1R6X9 (Paenarthrobacter aurescens (strain TC1)) Explore A1R6X9 Go to UniProtKB: A1R6X9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A1R6X9
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain D [auth B] SDF format, chain C [auth B] MOL2 format, chain D [auth B] MOL2 format, chain C [auth B] mmCIF format, chain D [auth B] mmCIF format, chain C [auth B]	C [auth B], D [auth B]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain C [auth B] Focus chain D [auth B] Interactions & Density Focus chain C [auth B] Focus chain D [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.199 (Depositor), 0.195 (DCC)
R-Value Work: 0.168 (Depositor), 0.169 (DCC)
R-Value Observed: 0.170 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 41.337	α = 90
b = 86.286	β = 94.75
c = 64.641	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
SHELXD	phasing
MLPHARE	phasing
DM	model building
ARP	model building
WARP	model building
HKL-3000	phasing
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
DM	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-08-11

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2010-08-11
Type: Initial release
Version 1.1: 2011-07-13
Changes: Source and taxonomy, Version format compliance
Version 1.2: 2024-10-09
Changes: Data collection, Database references, Derived calculations, Structure summary
