3NRA | pdb_00003nra

Crystal structure of an aspartate aminotransferase (YP_354942.1) from Rhodobacter sphaeroides 2.4.1 at 2.15 A resolution

PDB DOI: https://doi.org/10.2210/pdb3NRA/pdb

Classification: TRANSFERASE
Organism(s): Cereibacter sphaeroides 2.4.1
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2010-06-30 Released: 2010-08-04
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.15 Å
R-Value Free:
0.200 (Depositor), 0.199 (DCC)
R-Value Work:
0.153 (Depositor), 0.157 (DCC)
R-Value Observed:
0.156 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of an aspartate aminotransferase (YP_354942.1) from Rhodobacter sphaeroides 2.4.1 at 2.15 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 89.52 kDa
Atom Count: 6,808
Modeled Residue Count: 786
Deposited Residue Count: 814
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
aspartate aminotransferase	A, B	407	Cereibacter sphaeroides 2.4.1	Mutation(s): 0 Gene Names: RHOS4_34730, RSP_3437 EC: 2.6.1 (PDB Primary Data), 2.6.1.1 (UniProt)
UniProt
Find proteins for Q3IWP3 (Cereibacter sphaeroides (strain ATCC 17023 / DSM 158 / JCM 6121 / CCUG 31486 / LMG 2827 / NBRC 12203 / NCIMB 8253 / ATH 2.4.1.)) Explore Q3IWP3 Go to UniProtKB: Q3IWP3
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q3IWP3
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PEG Query on PEG Download:Ideal Coordinates CCD File SDF format, chain N [auth A] MOL2 format, chain N [auth A] mmCIF format, chain N [auth A]	N [auth A]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain N [auth A] Interactions & Density Focus chain N [auth A]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain T [auth B] SDF format, chain U [auth B] SDF format, chain V [auth B] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain T [auth B] MOL2 format, chain U [auth B] MOL2 format, chain V [auth B] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain T [auth B] mmCIF format, chain U [auth B] mmCIF format, chain V [auth B]	I [auth A] J [auth A] K [auth A] L [auth A] M [auth A] I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], T [auth B], U [auth B], V [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Interactions & Density Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain O [auth B] SDF format, chain P [auth B] SDF format, chain Q [auth B] SDF format, chain R [auth B] SDF format, chain S [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain O [auth B] MOL2 format, chain P [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] MOL2 format, chain S [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain O [auth B] mmCIF format, chain P [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain R [auth B] mmCIF format, chain S [auth B]	C [auth A] D [auth A] E [auth A] F [auth A] G [auth A] C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], O [auth B], P [auth B], Q [auth B], R [auth B], S [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B]

Modified Residues 3 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
CSD Query on CSD	A, B	L-PEPTIDE LINKING	C₃ H₇ N O₄ S		CYS
LLP Query on LLP	A, B	L-PEPTIDE LINKING	C₁₄ H₂₂ N₃ O₇ P		LYS
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.15 Å
R-Value Free: 0.200 (Depositor), 0.199 (DCC)
R-Value Work: 0.153 (Depositor), 0.157 (DCC)
R-Value Observed: 0.156 (Depositor)

Diffraction Data:

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 67.291	α = 90
b = 98.517	β = 90
c = 127.883	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SOLVE	phasing
MolProbity	model building
SCALA	data scaling
PDB_EXTRACT	data extraction
MOSFLM	data reduction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-08-04

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2010-08-04
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2014-11-12
Changes: Non-polymer description
Version 1.3: 2017-10-25
Changes: Author supporting evidence, Refinement description
Version 1.4: 2019-07-17
Changes: Data collection, Derived calculations, Refinement description
Version 1.5: 2023-02-01
Changes: Database references, Derived calculations
