3NHL

X-ray Crystallographic Structure Activity Relationship (SAR) of Casimiroin and its Analogs Bound to Human Quinone Reductase 2

• PDB DOI: https://doi.org/10.2210/pdb3NHL/pdb

• Classification: OXIDOREDUCTASE/OXIDOREDUCTASE INHIBITOR
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2010-06-14 Released: 2012-01-11
• Deposition Author(s): Sturdy, M.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.57 Å
• R-Value Free:
  0.231 (Depositor), 0.230 (DCC)
• R-Value Work:
  0.191 (Depositor), 0.190 (DCC)
• R-Value Observed:
  0.193 (Depositor)

Literature

X-ray Crystallographic Structure Activity Relationship (SAR) of Casimiroin and its Analogs Bound to Human Quinone Reductase 2

Sturdy, M.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 53.87 kDa
• Atom Count: 4,174
• Modelled Residue Count: 460
• Deposited Residue Count: 460
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Ribosyldihydronicotinamide dehydrogenase [quinone]	A, B	230	Homo sapiens	Mutation(s): 0  Gene Names: NQO2, NMOR2 EC: 1.10.99.2 (PDB Primary Data), 1.10.5.1 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P16083 (Homo sapiens) Explore P16083  Go to UniProtKB:  P16083
PHAROS:  P16083 GTEx:  ENSG00000124588

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
FAD	D [auth A], G [auth B]	FLAVIN-ADENINE DINUCLEOTIDE C27 H33 N9 O15 P2 VWWQXMAJTJZDQX-UYBVJOGSSA-N
YTR	E [auth A], H [auth B]	7,8-dimethoxy-1,4-dimethylquinolin-2(1H)-one C13 H15 N O3 DHJBSOKLGMWDBA-UHFFFAOYSA-N
ZN	C [auth A], F [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N

Binding Affinity Annotations
ID	Source	Binding Affinity
YTR	BindingDB:  3NHL	IC50: 9300 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.57 Å
• R-Value Free:  0.231 (Depositor), 0.230 (DCC)
• R-Value Work:  0.191 (Depositor), 0.190 (DCC)
• R-Value Observed: 0.193 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 56.104	α = 90
b = 83.163	β = 90
c = 106.473	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
HKL-2000	data collection
CCP4	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2012-01-11
Deposition Author(s): Sturdy, M.

Revision History

• Version 1.0: 2012-01-11
  Type: Initial release

• Version 1.1: 2017-11-08
  Changes: Refinement description
• Version 1.2: 2024-02-21
  Changes: Data collection, Database references, Derived calculations
