3NFI | pdb_00003nfi

Crystal structure of tandem winged helix domain of RNA polymerase I subunit A49


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:
    0.224 (Depositor), 0.205 (DCC)
  • R-Value Work:
    0.189 (Depositor), 0.203 (DCC)
  • R-Value Observed:
    0.190 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3NFI

This is version 1.3 of the entry. See complete history

Literature

RNA Polymerase I Contains a TFIIF-Related DNA-Binding Subcomplex.

Geiger, S.R.Lorenzen, K.Schreieck, A.Hanecker, P.Kostrewa, D.Heck, A.J.Cramer, P.

(2010) Mol Cell 39: 583-594

  • DOI: https://doi.org/10.1016/j.molcel.2010.07.028
  • Primary Citation Related Structures:
    3NFF, 3NFG, 3NFH, 3NFI

  • PubMed Abstract:

    The eukaryotic RNA polymerases Pol I, II, and III use different promoters to transcribe different classes of genes. Promoter usage relies on initiation factors, including TFIIF and TFIIE, in the case of Pol II. Here, we show that the Pol I-specific subunits A49 and A34.5 form a subcomplex that binds DNA and is related to TFIIF and TFIIE. The N-terminal regions of A49 and A34.5 form a dimerization module that stimulates polymerase-intrinsic RNA cleavage and has a fold that resembles the TFIIF core. The C-terminal region of A49 forms a "tandem winged helix" (tWH) domain that binds DNA with a preference for the upstream promoter nontemplate strand and is predicted in TFIIE. Similar domains are predicted in Pol III-specific subunits. Thus, Pol I/III subunits that have no counterparts in Pol II are evolutionarily related to Pol II initiation factors and may have evolved to mediate promoter specificity and transcription processivity.


  • Organizational Affiliation
    • Gene Center and Department of Biochemistry, Center for Integrated Protein Science CIPSM, Ludwig-Maximilians-Universität München, Feodor-Lynen-Strasse 25, 81377 Munich, Germany.

Macromolecule Content

  • Total Structure Weight: 136.06 kDa
  • Atom Count: 9,695
  • Modeled Residue Count: 1,092
  • Deposited Residue Count: 1,185
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase I subunit RPA49
A, B, C, D, E
237Saccharomyces cerevisiaeMutation(s): 2
Gene Names: N0880RPA49RRN13YNL248C
EC: 2.7.7.6
UniProt
Find proteins for Q01080 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q01080
Go to UniProtKB:  Q01080
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ01080
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PE4

Query on PE4



Download:Ideal Coordinates CCD File
F [auth E]2-{2-[2-(2-{2-[2-(2-ETHOXY-ETHOXY)-ETHOXY]-ETHOXY}-ETHOXY)-ETHOXY]-ETHOXY}-ETHANOL
C16 H34 O8
PJWQOENWHPEPKI-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, B, C, D, E
L-PEPTIDE LINKINGC5 H11 N O2 SeMET

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:  0.224 (Depositor), 0.205 (DCC)
  • R-Value Work:  0.189 (Depositor), 0.203 (DCC)
  • R-Value Observed: 0.190 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 85.11α = 90
b = 78.1β = 113.39
c = 100.67γ = 90
Software Package:
Software NamePurpose
ADSCdata collection
SHARPphasing
BUSTERrefinement
XDSdata reduction
XDSdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-09-08
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2015-03-25
    Changes: Atomic model, Database references
  • Version 1.3: 2024-11-06
    Changes: Data collection, Database references, Derived calculations, Structure summary
