3MMX | pdb_00003mmx

Bacillus anthracis NadD (baNadD) in complex with compound 1_02_3


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.55 Å
  • R-Value Free:
    0.263 (Depositor), 0.259 (DCC)
  • R-Value Work:
    0.221 (Depositor), 0.214 (DCC)
  • R-Value Observed:
    0.223 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3MMX

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

Complexes of bacterial nicotinate mononucleotide adenylyltransferase with inhibitors: implication for structure-based drug design and improvement.

Huang, N.Kolhatkar, R.Eyobo, Y.Sorci, L.Rodionova, I.Osterman, A.L.Mackerell, A.D.Zhang, H.

(2010) J Med Chem 53: 5229-5239

  • DOI: https://doi.org/10.1021/jm100377f
  • Primary Citation Related Structures:
    3MLA, 3MLB, 3MMX

  • PubMed Abstract:

    Bacterial nicotinate mononucleotide adenylyltransferase encoded by the essential gene nadD plays a central role in the synthesis of the redox cofactor NAD(+). The NadD enzyme is conserved in the majority of bacterial species and has been recognized as a novel target for developing new and potentially broad-spectrum antibacterial therapeutics. Here we report the crystal structures of Bacillus anthracis NadD in complex with three NadD inhibitors, including two analogues synthesized in the present study. These structures revealed a common binding site shared by different classes of NadD inhibitors and explored the chemical environment surrounding this site. The structural data obtained here also showed that the subtle changes in ligand structure can lead to significant changes in the binding mode, information that will be useful for future structure-based optimization and design of high affinity inhibitors.


  • Organizational Affiliation
    • Department of Biochemistry, University of Texas Southwestern Medical Center, 5323 Harry Hines Boulevard, Dallas, Texas 75390, USA.

Macromolecule Content

  • Total Structure Weight: 179.96 kDa
  • Atom Count: 12,172
  • Modeled Residue Count: 1,433
  • Deposited Residue Count: 1,528
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
nicotinate-nucleotide adenylyltransferase
A, B, C, D, E
A, B, C, D, E, F, G, H
191Bacillus anthracisMutation(s): 0
Gene Names: BAMEG_4595nadD
EC: 2.7.7.18
UniProt
Find proteins for C3L5T6 (Bacillus anthracis (strain CDC 684 / NRRL 3495))
Explore C3L5T6
Go to UniProtKB:  C3L5T6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC3L5T6
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
KJZ

Query on KJZ



Download:Ideal Coordinates CCD File
L [auth B],
R [auth D]
[(2E)-1-{4-[(2-chlorophenyl)amino]-4-oxobutanoyl}-2-(naphthalen-1-ylmethylidene)hydrazino]acetic acid
C23 H20 Cl N3 O4
HHHUDHYQFQBYIZ-AFUMVMLFSA-N
CIT

Query on CIT



Download:Ideal Coordinates CCD File
BA [auth G]
DA [auth H]
J [auth A]
M [auth B]
P [auth C]
BA [auth G],
DA [auth H],
J [auth A],
M [auth B],
P [auth C],
S [auth D],
V [auth E],
Y [auth F]
CITRIC ACID
C6 H8 O7
KRKNYBCHXYNGOX-UHFFFAOYSA-N
DMS

Query on DMS



Download:Ideal Coordinates CCD File
EA [auth H],
T [auth D],
W [auth E],
Z [auth F]
DIMETHYL SULFOXIDE
C2 H6 O S
IAZDPXIOMUYVGZ-UHFFFAOYSA-N
K

Query on K



Download:Ideal Coordinates CCD File
AA [auth G]
CA [auth H]
I [auth A]
K [auth B]
N [auth C]
AA [auth G],
CA [auth H],
I [auth A],
K [auth B],
N [auth C],
O [auth C],
Q [auth D],
U [auth E],
X [auth F]
POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.55 Å
  • R-Value Free:  0.263 (Depositor), 0.259 (DCC)
  • R-Value Work:  0.221 (Depositor), 0.214 (DCC)
  • R-Value Observed: 0.223 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 295.151α = 90
b = 46.446β = 91.42
c = 114.952γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
MOLREPphasing
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-07-28
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2014-06-11
    Changes: Database references
  • Version 1.3: 2023-09-06
    Changes: Data collection, Database references, Derived calculations, Refinement description
