3LRQ | pdb_00003lrq

Crystal structure of the U-box domain of human ubiquitin-protein ligase (E3), NORTHEAST STRUCTURAL GENOMICS CONSORTIUM TARGET HR4604D.

PDB DOI: https://doi.org/10.2210/pdb3LRQ/pdb

Classification: LIGASE
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2010-02-11 Released: 2010-03-23
Deposition Author(s): Kuzin, A., Chen, Y., Seetharaman, J., Mao, M., Xiao, R., Ciccosanti, C., Shastry, R., Everett, J.K., Nair, R., Acton, T.B., Rost, B., Montelione, G.T., Tong, L., Hunt, J.F., Northeast Structural Genomics Consortium (NESG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.29 Å
R-Value Free:
0.245 (Depositor), 0.238 (DCC)
R-Value Work:
0.190 (Depositor), 0.185 (DCC)
R-Value Observed:
0.193 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.4 of the entry. See complete history.

Literature

E3 UBIQUITIN-PROTEIN LIGASE RING DOMAIN FROM HUMAN TRIPARTITE MOTIF-CONTAINING PROTEIN 37 (TRIM37), NORTHEAST STRUCTURAL GENOMICS CONSORTIUM TARGET HR4604D.

Kuzin, A., Chen, Y., Seetharaman, J., Mao, M., Xiao, R., Ciccosanti, C., Shastry, R., Everett, J.K., Nair, R., Acton, T.B., Rost, B., Montelione, G.T., Tong, L., Hunt, J.F.

To be published.

Macromolecule Content

Total Structure Weight: 48.75 kDa
Atom Count: 2,827
Modeled Residue Count: 328
Deposited Residue Count: 400
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
E3 ubiquitin-protein ligase TRIM37	A, B, C, D	100	Homo sapiens	Mutation(s): 0 Gene Names: KIAA0898, MUL, POB1, TRIM37 EC: 6.3.2 (PDB Primary Data), 2.3.2.27 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for O94972 (Homo sapiens) Explore O94972 Go to UniProtKB: O94972
PHAROS: O94972 GTEx: ENSG00000108395
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O94972
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain L [auth D] SDF format, chain K [auth D] SDF format, chain J [auth C] SDF format, chain I [auth C] SDF format, chain H [auth B] SDF format, chain G [auth B] SDF format, chain F [auth A] SDF format, chain E [auth A] MOL2 format, chain L [auth D] MOL2 format, chain K [auth D] MOL2 format, chain J [auth C] MOL2 format, chain I [auth C] MOL2 format, chain H [auth B] MOL2 format, chain G [auth B] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] mmCIF format, chain L [auth D] mmCIF format, chain K [auth D] mmCIF format, chain J [auth C] mmCIF format, chain I [auth C] mmCIF format, chain H [auth B] mmCIF format, chain G [auth B] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A]	E [auth A] F [auth A] G [auth B] H [auth B] I [auth C] E [auth A], F [auth A], G [auth B], H [auth B], I [auth C], J [auth C], K [auth D], L [auth D]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth C] Focus chain J [auth C] Focus chain K [auth D] Focus chain L [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth C] Focus chain J [auth C] Focus chain K [auth D] Focus chain L [auth D]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B, C, D	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.29 Å
R-Value Free: 0.245 (Depositor), 0.238 (DCC)
R-Value Work: 0.190 (Depositor), 0.185 (DCC)
R-Value Observed: 0.193 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 72.544	α = 90
b = 34.922	β = 90.78
c = 86.709	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
ADSC	data collection
HKL-2000	data reduction
HKL-2000	data scaling
SnB	phasing
REFMAC	refinement

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-03-23

Deposition Author(s):

Northeast Structural Genomics Consortium (NESG)

Revision History (Full details and data files)

Version 1.0: 2010-03-23
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2017-11-01
Changes: Refinement description
Version 1.3: 2019-07-17
Changes: Data collection, Derived calculations, Refinement description
Version 1.4: 2024-11-20
Changes: Data collection, Database references, Derived calculations, Structure summary
