3L7H | pdb_00003l7h

Insights into dynein assembly from a dynein intermediate chain light chain Roadblock structure

PDB DOI: https://doi.org/10.2210/pdb3L7H/pdb

Classification: PROTEIN TRANSPORT
Organism(s): Drosophila melanogaster
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2009-12-28 Released: 2010-05-12
Deposition Author(s): Hall, J., Karplus, P.A., Barbar, E.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.95 Å
R-Value Free:
0.254 (Depositor), 0.269 (DCC)
R-Value Work:
0.193 (Depositor), 0.209 (DCC)
R-Value Observed:
0.199 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3L7H

This is version 1.2 of the entry. See complete history.

Literature

Insights into dynein assembly from a dynein intermediate chain light chain Roadblock structure

Hall, J., Karplus, P.A., Barbar, E.

To be published.

Macromolecule Content

Total Structure Weight: 43.35 kDa
Atom Count: 3,120
Modeled Residue Count: 360
Deposited Residue Count: 388
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
RE64145p	A, B, C, D	97	Drosophila melanogaster	Mutation(s): 0 Gene Names: CG10751, Dmel_CG10751, robl
UniProt
Find proteins for Q7KMS3 (Drosophila melanogaster) Explore Q7KMS3 Go to UniProtKB: Q7KMS3
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q7KMS3
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.95 Å
R-Value Free: 0.254 (Depositor), 0.269 (DCC)
R-Value Work: 0.193 (Depositor), 0.209 (DCC)
R-Value Observed: 0.199 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 56.218	α = 90
b = 58.693	β = 101.8
c = 65.095	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
PHASER	phasing
REFMAC	refinement
MOSFLM	data reduction
SCALA	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-05-12

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2010-05-12
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2023-09-06
Changes: Data collection, Database references, Refinement description
