3KTI | pdb_00003kti

Structure of ClpP in complex with ADEP1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:
    0.253 (Depositor), 0.218 (DCC)
  • R-Value Work:
    0.217 (Depositor), 0.224 (DCC)

wwPDB Validation 3D Report Full Report

Validation slider image for 3KTI

This is version 1.3 of the entry. See complete history

Literature

Structures of ClpP in complex with acyldepsipeptide antibiotics reveal its activation mechanism

Lee, B.-G.Park, E.Y.Lee, K.-E.Jeon, H.Sung, K.H.Paulsen, H.Rubsamen-Schaeff, H.Brotz-Oesterhelt, H.Song, H.K.

(2010) Nat Struct Mol Biol 17: 471-478

  • DOI: https://doi.org/10.1038/nsmb.1787
  • Primary Citation Related Structures:
    3KTG, 3KTH, 3KTI, 3KTJ, 3KTK

  • PubMed Abstract:

    Clp-family proteins are prototypes for studying the mechanism of ATP-dependent proteases because the proteolytic activity of the ClpP core is tightly regulated by activating Clp-ATPases. Nonetheless, the proteolytic activation mechanism has remained elusive because of the lack of a complex structure. Acyldepsipeptides (ADEPs), a recently discovered class of antibiotics, activate and disregulate ClpP. Here we have elucidated the structural changes underlying the ClpP activation process by ADEPs. We present the structures of Bacillus subtilis ClpP alone and in complex with ADEP1 and ADEP2. The structures show the closed-to-open-gate transition of the ClpP N-terminal segments upon activation as well as conformational changes restricted to the upper portion of ClpP. The direction of the conformational movement and the hydrophobic clustering that stabilizes the closed structure are markedly different from those of other ATP-dependent proteases, providing unprecedented insights into the activation of ClpP.


  • Organizational Affiliation
    • School of Life Sciences and Biotechnology, Korea University, Seoul, Korea.

Macromolecule Content

  • Total Structure Weight: 161.09 kDa
  • Atom Count: 10,432
  • Modeled Residue Count: 1,267
  • Deposited Residue Count: 1,442
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP-dependent Clp protease proteolytic subunit
A, B, C, D, E
A, B, C, D, E, F, G
199Bacillus subtilisMutation(s): 0
Gene Names: clpPyvdNBSU34540
EC: 3.4.21.92
UniProt
Find proteins for P80244 (Bacillus subtilis (strain 168))
Explore P80244
Go to UniProtKB:  P80244
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP80244
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:  Sequence   |   3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Acyldepsipeptide 1
H, I, J, K, L
H, I, J, K, L, M, N
7N/AMutation(s): 0

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NHE

Query on NHE



Download:Ideal Coordinates CCD File
BA [auth G]
P [auth A]
R [auth B]
T [auth C]
V [auth D]
BA [auth G],
P [auth A],
R [auth B],
T [auth C],
V [auth D],
X [auth E],
Z [auth F]
2-[N-CYCLOHEXYLAMINO]ETHANE SULFONIC ACID
C8 H17 N O3 S
MKWKNSIESPFAQN-UHFFFAOYSA-N
DMS

Query on DMS



Download:Ideal Coordinates CCD File
AA [auth G]
O [auth A]
Q [auth B]
S [auth C]
U [auth D]
AA [auth G],
O [auth A],
Q [auth B],
S [auth C],
U [auth D],
W [auth E],
Y [auth F]
DIMETHYL SULFOXIDE
C2 H6 O S
IAZDPXIOMUYVGZ-UHFFFAOYSA-N
Modified Residues  2 Unique
IDChains TypeFormula2D DiagramParent
MAA
Query on MAA
H, I, J, K, L
H, I, J, K, L, M, N
L-PEPTIDE LINKINGC4 H9 N O2ALA
MP8
Query on MP8
H, I, J, K, L
H, I, J, K, L, M, N
L-PEPTIDE LINKINGC6 H11 N O2PRO

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:  0.253 (Depositor), 0.218 (DCC)
  • R-Value Work:  0.217 (Depositor), 0.224 (DCC)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 121.645α = 90
b = 151.756β = 120.03
c = 100.665γ = 90
Software Package:
Software NamePurpose
CNSrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-03-23
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2013-02-27
    Changes: Other
  • Version 1.3: 2025-03-26
    Changes: Data collection, Database references, Derived calculations, Structure summary
