3KKG | pdb_00003kkg

Crystal structure of Putative SnoaL-like polyketide cyclase (YP_509242.1) from Jannaschia Sp. CCS1 at 1.40 A resolution

• PDB DOI: https://doi.org/10.2210/pdb3KKG/pdb

• Classification: LYASE
• Organism(s): Jannaschia sp. CCS1
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2009-11-05 Released: 2009-12-01
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.40 Å
• R-Value Free:
  0.198 (Depositor), 0.200 (DCC)
• R-Value Work:
  0.181 (Depositor), 0.186 (DCC)
• R-Value Observed:
  0.182 (Depositor)

Literature

Crystal structure of Putative SnoaL-like polyketide cyclase (YP_509242.1) from Jannaschia Sp. CCS1 at 1.40 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 16.65 kDa
• Atom Count: 1,463
• Modeled Residue Count: 144
• Deposited Residue Count: 146
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative SnoaL-like polyketide cyclase	A	146	Jannaschia sp. CCS1	Mutation(s): 0  Gene Names: Jann_1300
UniProt
Find proteins for A0ACD6B876 (Jannaschia sp. (strain CCS1)) Explore A0ACD6B876  Go to UniProtKB:  A0ACD6B876

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PGE	E [auth A]	TRIETHYLENE GLYCOL C6 H14 O4 ZIBGPFATKBEMQZ-UHFFFAOYSA-N
PEG	C [auth A], D [auth A]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
CL	B [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.40 Å
• R-Value Free:  0.198 (Depositor), 0.200 (DCC)
• R-Value Work:  0.181 (Depositor), 0.186 (DCC)
• R-Value Observed: 0.182 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33KKG

Space Group: P 6₅ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 57.036	α = 90
b = 57.036	β = 90
c = 181.14	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
SCALA	data scaling
PDB_EXTRACT	data extraction
MOSFLM	data reduction
SHARP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-12-01
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2009-12-01
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Source and taxonomy, Version format compliance
• Version 1.2: 2017-10-25
  Changes: Author supporting evidence, Refinement description
• Version 1.3: 2019-07-17
  Changes: Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-02-01
  Changes: Database references, Derived calculations
• Version 1.5: 2024-11-27
  Changes: Data collection, Structure summary
