3KER | pdb_00003ker

D-Dopachrome tautomerase (D-DT)/ macrophage migration inhibitory factor 2 (MIF2) complexed with inhibitor 4-IPP


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.78 Å
  • R-Value Free:
    0.238 (Depositor), 0.237 (DCC)
  • R-Value Work:
    0.222 (Depositor), 0.222 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3KER

Ligand Structure Quality Assessment


This is version 1.5 of the entry. See complete history

Literature

Targeting distinct tautomerase sites of D-DT and MIF with a single molecule for inhibition of neutrophil lung recruitment.

Rajasekaran, D.Zierow, S.Syed, M.Bucala, R.Bhandari, V.Lolis, E.J.

(2014) FASEB J 28: 4961-4971

  • DOI: https://doi.org/10.1096/fj.14-256636
  • Primary Citation Related Structures:
    3KAN, 3KER, 4Q3F

  • PubMed Abstract:

    We report a new inflammatory activity for extracellular d-dopachrome tautomerase (D-DT), the recruitment of neutrophils to the lung on D-DT intratracheal installation of C57BL/6J mice with an EC50 of 5.6 μg. We also find that D-DT and macrophage migration inhibitory factor (MIF) have additive effects in neutrophil recruitment. Although the tautomerase site of D-DT and its homologue MIF are biophysically very different, 4-iodo-6-phenylpyrimidine (4-IPP) forms a covalent bond with Pro-1 of both proteins, resulting in a 6-phenylpyrimidine (6-PP) adduct. Recruitment of neutrophils to the lung for the 6-PP adducts of D-DT and MIF are reduced by ∼ 50% relative to the apo proteins, demonstrating that an unmodified Pro-1 is important for this activity, but there is no cooperativity in inhibition of the proteins together. The differences in the binding mode of the 6-PP adduct for D-DT was determined by crystallographic studies at 1.13 Å resolution and compared to the structure of the MIF-6-PP complex. There are major differences in the location of the 6-PP adduct to the D-DT and MIF active sites that provide insight into the lack of cooperativity by 4-IPP and into tuning the properties of the covalent inhibitors of D-DT and MIF that are necessary for the development of therapeutic small molecules against neutrophil damage from lung infections such as Pseudomonas aeruginosa in cystic fibrosis and immunocompromised patients.


  • Organizational Affiliation
    • Department of Pharmacology.

Macromolecule Content

  • Total Structure Weight: 52.98 kDa
  • Atom Count: 3,704
  • Modeled Residue Count: 468
  • Deposited Residue Count: 468
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
D-dopachrome decarboxylase
A, B, C, D
117Mus musculusMutation(s): 0
Gene Names: Ddt
EC: 4.1.1.84
UniProt
Find proteins for O35215 (Mus musculus)
Explore O35215
Go to UniProtKB:  O35215
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO35215
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
RW1

Query on RW1



Download:Ideal Coordinates CCD File
E [auth A],
J [auth B],
O [auth C],
T [auth D]
4-phenylpyrimidine
C10 H8 N2
MKLQPIYLZMLAER-UHFFFAOYSA-N
CL

Query on CL



Download:Ideal Coordinates CCD File
F [auth A]
G [auth A]
I [auth A]
K [auth B]
L [auth B]
F [auth A],
G [auth A],
I [auth A],
K [auth B],
L [auth B],
N [auth B],
P [auth C],
Q [auth C],
S [auth C],
U [auth D],
V [auth D],
X [auth D]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
NA

Query on NA



Download:Ideal Coordinates CCD File
H [auth A],
M [auth B],
R [auth C],
W [auth D]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.78 Å
  • R-Value Free:  0.238 (Depositor), 0.237 (DCC)
  • R-Value Work:  0.222 (Depositor), 0.222 (DCC)
Space Group: P 63
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 82.172α = 90
b = 82.172β = 90
c = 144.253γ = 120
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
PHASERphasing
CNSrefinement
PDB_EXTRACTdata extraction
HKL-2000data collection
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-10-13
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2017-11-01
    Changes: Refinement description
  • Version 1.3: 2020-10-21
    Changes: Database references, Derived calculations
  • Version 1.4: 2023-09-06
    Changes: Data collection, Database references, Refinement description
  • Version 1.5: 2024-11-27
    Changes: Structure summary
