3I0Q | pdb_00003i0q

Crystal Structure of the AMP-bound complex of Spectinomycin Phosphotransferase, APH(9)-Ia


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free:
    0.346 (Depositor), 0.344 (DCC)
  • R-Value Work:
    0.262 (Depositor), 0.263 (DCC)
  • R-Value Observed:
    0.262 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3I0Q

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Structure of the antibiotic resistance factor spectinomycin phosphotransferase from Legionella pneumophila.

Fong, D.H.Lemke, C.T.Hwang, J.Xiong, B.Berghuis, A.M.

(2010) J Biological Chem 285: 9545-9555

  • DOI: https://doi.org/10.1074/jbc.M109.038364
  • Primary Citation Related Structures:
    3I0O, 3I0Q, 3I1A

  • PubMed Abstract:

    Aminoglycoside phosphotransferases (APHs) constitute a diverse group of enzymes that are often the underlying cause of aminoglycoside resistance in the clinical setting. Several APHs have been extensively characterized, including the elucidation of the three-dimensional structure of two APH(3') isozymes and an APH(2'') enzyme. Although many APHs are plasmid-encoded and are capable of inactivating numerous 2-deoxystreptmaine aminoglycosides with multiple regiospecificity, APH(9)-Ia, isolated from Legionella pneumophila, is an unusual enzyme among the APH family for its chromosomal origin and its specificity for a single non-2-deoxystreptamine aminoglycoside substrate, spectinomycin. We describe here the crystal structures of APH(9)-Ia in its apo form, its binary complex with the nucleotide, AMP, and its ternary complex bound with ADP and spectinomycin. The structures reveal that APH(9)-Ia adopts the bilobal protein kinase-fold, analogous to the APH(3') and APH(2'') enzymes. However, APH(9)-Ia differs significantly from the other two types of APH enzymes in its substrate binding area and that it undergoes a conformation change upon ligand binding. Moreover, kinetic assay experiments indicate that APH(9)-Ia has stringent substrate specificity as it is unable to phosphorylate substrates of choline kinase or methylthioribose kinase despite high structural resemblance. The crystal structures of APH(9)-Ia demonstrate and expand our understanding of the diversity of the APH family, which in turn will facilitate the development of new antibiotics and inhibitors.


  • Organizational Affiliation
    • Department of Biochemistry, McGill University, Montreal, Quebec H3G 1Y6.

Macromolecule Content

  • Total Structure Weight: 40.05 kDa
  • Atom Count: 2,634
  • Modeled Residue Count: 316
  • Deposited Residue Count: 339
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Spectinomycin phosphotransferase339Legionella pneumophila serogroup 1Mutation(s): 0
Gene Names: aphaph9
UniProt
Find proteins for O06916 (Legionella pneumophila)
Explore O06916
Go to UniProtKB:  O06916
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO06916
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free:  0.346 (Depositor), 0.344 (DCC)
  • R-Value Work:  0.262 (Depositor), 0.263 (DCC)
  • R-Value Observed: 0.262 (Depositor)
Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 74.466α = 90
b = 74.466β = 90
c = 135.526γ = 120
Software Package:
Software NamePurpose
CBASSdata collection
PHASERphasing
CNSrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-01-19
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2023-09-06
    Changes: Data collection, Database references, Derived calculations, Refinement description
