3HRG

Crystal structure of Bacteroides thetaiotaomicron BT_3980, protein with actin-like ATPase fold and unknown function (NP_812891.1) from BACTEROIDES THETAIOTAOMICRON VPI-5482 at 1.85 A resolution

• PDB DOI: https://doi.org/10.2210/pdb3HRG/pdb

• Classification: structural genomics, unknown function
• Organism(s): Bacteroides thetaiotaomicron VPI-5482
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2009-06-09 Released: 2009-06-23
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.85 Å
• R-Value Free: 0.240
• R-Value Work: 0.193
• R-Value Observed: 0.195

Literature

Crystal structure of Bacteroides thetaiotaomicron BT_3980, protein with actin-like ATPase fold and unknown function (NP_812891.1) from BACTEROIDES THETAIOTAOMICRON VPI-5482 at 1.85 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 30.99 kDa
• Atom Count: 2,619
• Modelled Residue Count: 257
• Deposited Residue Count: 257
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
uncharacterized protein BT_3980 with actin-like ATPase fold	A	257	Bacteroides thetaiotaomicron VPI-5482	Mutation(s): 0  Gene Names: BT_3980, NP_812891.1
UniProt
Find proteins for Q8A0P1 (Bacteroides thetaiotaomicron (strain ATCC 29148 / DSM 2079 / JCM 5827 / CCUG 10774 / NCTC 10582 / VPI-5482 / E50)) Explore Q8A0P1  Go to UniProtKB:  Q8A0P1

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PEG	D [auth A]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
EDO	C [auth A]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N
UNL	B [auth A]	Unknown ligand LYCAIKOWRPUZTN-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.85 Å
• R-Value Free: 0.240
• R-Value Work: 0.193
• R-Value Observed: 0.195
• Space Group: P 2₁ 2₁ 2
• Diffraction Data: https://doi.org/10.18430/M33HRG

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 64.706	α = 90
b = 91.181	β = 90
c = 48.62	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-06-23
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2009-06-23
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.2: 2017-10-25
  Changes: Author supporting evidence, Refinement description
• Version 1.3: 2019-07-24
  Changes: Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-02-01
  Changes: Database references, Derived calculations
• Version 1.5: 2024-10-30
  Changes: Data collection, Structure summary
