3HEZ | pdb_00003hez

Exploring backbone pattern in alpha/beta-peptide helix bundles: The GCN4-pLI side chain sequence on different (alpha-alpha-alpha-beta) backbones

• PDB DOI: https://doi.org/10.2210/pdb3HEZ/pdb

• Classification: DE NOVO PROTEIN
• Mutation(s): No


• Deposited: 2009-05-10 Released: 2009-05-19
• Deposition Author(s): Horne, W.S., Gellman, S.H.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:
  0.201 (Depositor), 0.199 (DCC)
• R-Value Work:
  0.157 (Depositor), 0.157 (DCC)
• R-Value Observed:
  0.159 (Depositor)

Starting Model: experimental

Literature

Exploring backbone pattern in GCN4-pLI alpha/beta-peptide helix bundles

Horne, W.S., Gellman, S.H.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C3  (Explore in 3D)
Global Stoichiometry: Homo 3-mer - A3

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 13.12 kDa
• Atom Count: 1,075
• Modeled Residue Count: 102
• Deposited Residue Count: 102
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
alpha/beta peptide with the GCN4-pLI side chain sequence on an (alpha-alpha-alpha-beta) backbone	A, B, C	34	N/A	Mutation(s): 0

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
TAM	H [auth B]	TRIS(HYDROXYETHYL)AMINOMETHANE C7 H17 N O3 GKODZWOPPOTFGA-UHFFFAOYSA-N
GOL	E [auth A], F [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
TBU	D [auth A], G [auth A], I [auth C]	TERTIARY-BUTYL ALCOHOL C4 H10 O DKGAVHZHDRPRBM-UHFFFAOYSA-N

Modified Residues  3 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
B3A	A, B, C	L-PEPTIDE LINKING	C4 H9 N O2		ALA
B3E	A, B, C	L-PEPTIDE LINKING	C6 H11 N O4		GLU
B3K	A, B, C	L-PEPTIDE LINKING	C7 H16 N2 O2		LYS
B3L	A, B, C	L-PEPTIDE LINKING	C7 H15 N O2		--
B3Q	A, B, C	L-PEPTIDE LINKING	C6 H12 N2 O3		--
BIL	A, B, C	L-PEPTIDE LINKING	C7 H15 N O2		--

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:  0.201 (Depositor), 0.199 (DCC)
• R-Value Work:  0.157 (Depositor), 0.157 (DCC)
• R-Value Observed: 0.159 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 31.817	α = 90
b = 43.082	β = 96
c = 37.001	γ = 90

Software Package:

Software Name	Purpose
PROTEUM PLUS	data collection
PHASER	phasing
REFMAC	refinement
PROTEUM PLUS	data reduction
PROTEUM PLUS	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-05-19
Deposition Author(s): Horne, W.S., Gellman, S.H.

Revision History

• Version 1.0: 2009-05-19
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Non-polymer description, Version format compliance
• Version 1.2: 2023-09-06
  Changes: Data collection, Database references, Derived calculations, Refinement description
• Version 2.0: 2023-11-15
  Changes: Atomic model, Data collection
