3GZS | pdb_00003gzs

Crystal structure of a susd superfamily protein (bf3413) from bacteroides fragilis nctc 9343 at 2.10 A resolution

PDB DOI: https://doi.org/10.2210/pdb3GZS/pdb

Classification: SUGAR BINDING PROTEIN
Organism(s): Bacteroides fragilis NCTC 9343
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-04-07 Released: 2009-04-21
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.09 Å
R-Value Free:
0.198 (Depositor), 0.207 (DCC)
R-Value Work:
0.156 (Depositor), 0.166 (DCC)
R-Value Observed:
0.158 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.4 of the entry. See complete history.

Literature

Crystal structure of SusD superfamily protein (YP_213019.1) from Bacteroides fragilis NCTC 9343 at 2.10 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 117.91 kDa
Atom Count: 8,328
Modeled Residue Count: 990
Deposited Residue Count: 1,030
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized SusD superfamily protein	A, B	515	Bacteroides fragilis NCTC 9343	Mutation(s): 0 Gene Names: BF3413, YP_213019.1
UniProt
Find proteins for Q5L9X2 (Bacteroides fragilis (strain ATCC 25285 / DSM 2151 / CCUG 4856 / JCM 11019 / LMG 10263 / NCTC 9343 / Onslow / VPI 2553 / EN-2)) Explore Q5L9X2 Go to UniProtKB: Q5L9X2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q5L9X2
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain J [auth B] SDF format, chain K [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain J [auth B] MOL2 format, chain K [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain J [auth B] mmCIF format, chain K [auth B]	C [auth A] D [auth A] E [auth A] F [auth A] J [auth B] C [auth A], D [auth A], E [auth A], F [auth A], J [auth B], K [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain J [auth B] Focus chain K [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain J [auth B] Focus chain K [auth B]
ACT Query on ACT Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain L [auth B] SDF format, chain M [auth B] SDF format, chain N [auth B] SDF format, chain O [auth B] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain L [auth B] MOL2 format, chain M [auth B] MOL2 format, chain N [auth B] MOL2 format, chain O [auth B] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain L [auth B] mmCIF format, chain M [auth B] mmCIF format, chain N [auth B] mmCIF format, chain O [auth B]	G [auth A] H [auth A] I [auth A] L [auth B] M [auth B] G [auth A], H [auth A], I [auth A], L [auth B], M [auth B], N [auth B], O [auth B]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Interactions & Density Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B]

Modified Residues 2 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET
OCS Query on OCS	A, B	L-PEPTIDE LINKING	C₃ H₇ N O₅ S		CYS

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.09 Å
R-Value Free: 0.198 (Depositor), 0.207 (DCC)
R-Value Work: 0.156 (Depositor), 0.166 (DCC)
R-Value Observed: 0.158 (Depositor)

Diffraction Data:

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 88.921	α = 90
b = 50.377	β = 108.05
c = 117.95	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
XSCALE	data scaling
PDB_EXTRACT	data extraction
MAR345	data collection
XDS	data reduction
autoSHARP	phasing
SHELXD	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2009-04-21

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2009-04-21
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Source and taxonomy, Version format compliance
Version 1.2: 2017-11-01
Changes: Refinement description
Version 1.3: 2019-07-24
Changes: Data collection, Derived calculations, Refinement description
Version 1.4: 2023-02-01
Changes: Database references, Derived calculations
