3GEL | pdb_00003gel

O-Methylphosphorylated Torpedo Acetylcholinesterase Obtained by Reaction with Methyl Paraoxon (AGED)

PDB DOI: https://doi.org/10.2210/pdb3GEL/pdb

Classification: HYDROLASE
Organism(s): Tetronarce californica
Mutation(s): No

Deposited: 2009-02-25 Released: 2010-09-22
Deposition Author(s): Legler, P.M., Millard, C.B.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.39 Å
R-Value Free:
0.240 (Depositor), 0.239 (DCC)
R-Value Work:
0.210 (Depositor), 0.209 (DCC)
R-Value Observed:
0.212 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 3GEL

This is version 1.2 of the entry. See complete history.

Literature

O-Methylphosphorylated Torpedo Acetylcholinesterase Obtained by Reaction with Methyl Paraoxon (AGED)

Millard, C.B., Legler, P.M., Soojhawon, I.

To be published.

Macromolecule Content

Total Structure Weight: 60.29 kDa
Atom Count: 4,559
Modeled Residue Count: 527
Deposited Residue Count: 532
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Acetylcholinesterase	A	532	Tetronarce californica	Mutation(s): 0 EC: 3.1.1.7
UniProt
Find proteins for P04058 (Tetronarce californica) Explore P04058 Go to UniProtKB: P04058
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P04058
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
OMH Query on OMH	A	L-PEPTIDE LINKING	C₄ H₁₀ N O₆ P		SER

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.39 Å
R-Value Free: 0.240 (Depositor), 0.239 (DCC)
R-Value Work: 0.210 (Depositor), 0.209 (DCC)
R-Value Observed: 0.212 (Depositor)

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 111.726	α = 90
b = 111.726	β = 90
c = 136.853	γ = 120

Software Package:

Software Name	Purpose
PROTEUM PLUS	data collection
AMoRE	phasing
REFMAC	refinement
SAINT	data reduction
SCALA	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-09-22

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2010-09-22
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2023-09-06
Changes: Data collection, Database references, Derived calculations, Refinement description
