3GDC | pdb_00003gdc

Crystal structure of multicopper oxidase

PDB DOI: https://doi.org/10.2210/pdb3GDC/pdb

Classification: OXIDOREDUCTASE
Organism(s): Arthrobacter sp. FB24
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-02-24 Released: 2010-03-09
Deposition Author(s): MacPherson, I.S., Lee, W.C., Liang, T.I., Murphy, M.E.P.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.225 (Depositor), 0.244 (DCC)
R-Value Work:
0.191 (Depositor)
R-Value Observed:
0.193 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

A trimeric multicopper oxidase provides an evolutionary link to nitrite reductase

MacPherson, I.S., Lee, W.C., Liang, T.I., Murphy, M.E.P.

To be published.

Macromolecule Content

Total Structure Weight: 97.53 kDa
Atom Count: 7,259
Modeled Residue Count: 859
Deposited Residue Count: 864
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Multicopper oxidase	A, B, C	288	Arthrobacter sp. FB24	Mutation(s): 0 Gene Names: Arth_4419 EC: 1.10.3.2
UniProt
Find proteins for A0ACD6B8D3 (Arthrobacter sp. (strain FB24)) Explore A0ACD6B8D3 Go to UniProtKB: A0ACD6B8D3
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0ACD6B8D3
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CU Query on CU Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain O [auth C] SDF format, chain Q [auth C] SDF format, chain P [auth C] SDF format, chain N [auth C] SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain J [auth B] SDF format, chain I [auth B] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain G [auth A] MOL2 format, chain O [auth C] MOL2 format, chain Q [auth C] MOL2 format, chain P [auth C] MOL2 format, chain N [auth C] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain J [auth B] MOL2 format, chain I [auth B] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain G [auth A] mmCIF format, chain O [auth C] mmCIF format, chain Q [auth C] mmCIF format, chain P [auth C] mmCIF format, chain N [auth C] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain J [auth B] mmCIF format, chain I [auth B] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A] E [auth A] F [auth A] G [auth A] I [auth B] D [auth A], E [auth A], F [auth A], G [auth A], I [auth B], J [auth B], K [auth B], L [auth B], N [auth C], O [auth C], P [auth C], Q [auth C]	COPPER (II) ION Cu JPVYNHNXODAKFH-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain P [auth C] Focus chain Q [auth C] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain P [auth C] Focus chain Q [auth C]
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain R [auth C] SDF format, chain M [auth B] MOL2 format, chain H [auth A] MOL2 format, chain R [auth C] MOL2 format, chain M [auth B] mmCIF format, chain H [auth A] mmCIF format, chain R [auth C] mmCIF format, chain M [auth B]	H [auth A], M [auth B], R [auth C]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain M [auth B] Focus chain R [auth C] Interactions & Density Focus chain H [auth A] Focus chain M [auth B] Focus chain R [auth C]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.225 (Depositor), 0.244 (DCC)
R-Value Work: 0.191 (Depositor)
R-Value Observed: 0.193 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 133.956	α = 90
b = 50.705	β = 107.86
c = 134.667	γ = 90

Software Package:

Software Name	Purpose
Blu-Ice	data collection
SOLVE	phasing
REFMAC	refinement
MOSFLM	data reduction
SCALA	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-03-09

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2010-03-09
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2024-02-21
Changes: Data collection, Database references, Derived calculations
