3FLZ

P38 kinase crystal structure in complex WITH 8-Methyl-6-phenoxy-2-(tetrahydro-pyran-4-ylamino)-8H-pyrido[2,3-d]pyrimidin-7-one

• PDB DOI: https://doi.org/10.2210/pdb3FLZ/pdb

• Classification: SIGNALING PROTEIN, TRANSFERASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2008-12-19 Released: 2009-12-22
• Deposition Author(s): Kuglstatter, A., Ghate, M.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.23 Å
• R-Value Free: 0.251
• R-Value Work: 0.212
• R-Value Observed: 0.214

Starting Model: experimental

Literature

The Discovery of Pamapimod and R1487 as Orally Bioavailable and Highly Selective Inhibitors of p38 Map Kinase

Soth, M., Kuglstatter, A., Goldstein, D.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 43.1 kDa
• Atom Count: 3,034
• Modelled Residue Count: 347
• Deposited Residue Count: 372
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitogen-activated protein kinase 14	A	372	Homo sapiens	Mutation(s): 0  Gene Names: CSBP, CSBP1, CSBP2, CSPB1, MAPK14, MXI2 EC: 2.7.11.24
UniProt & NIH Common Fund Data Resources
Find proteins for Q16539 (Homo sapiens) Explore Q16539  Go to UniProtKB:  Q16539
PHAROS:  Q16539 GTEx:  ENSG00000112062

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
FLZ	B [auth A]	8-methyl-6-phenoxy-2-(tetrahydro-2H-pyran-4-ylamino)pyrido[2,3-d]pyrimidin-7(8H)-one C19 H20 N4 O3 MQCPQHIQHJWGCZ-UHFFFAOYSA-N

Binding Affinity Annotations
ID	Source	Binding Affinity
FLZ	BindingDB:  3FLZ	IC50: 106 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.23 Å
• R-Value Free: 0.251
• R-Value Work: 0.212
• R-Value Observed: 0.214
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 45.829	α = 90
b = 85.978	β = 90
c = 126.057	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
CNS	refinement
ADSC	data collection
DENZO	data reduction
SCALEPACK	data scaling
CNS	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-12-22
Deposition Author(s): Kuglstatter, A., Ghate, M.

Revision History

• Version 1.0: 2009-12-22
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Refinement description, Version format compliance
• Version 1.2: 2019-07-24
  Changes: Data collection, Refinement description
• Version 1.3: 2023-09-06
  Changes: Data collection, Database references, Derived calculations, Refinement description
