3FJV | pdb_00003fjv

Crystal structure of novel protein of unknown function (YP_111841.1) from BURKHOLDERIA PSEUDOMALLEI K96243 at 1.90 A resolution

• PDB DOI: https://doi.org/10.2210/pdb3FJV/pdb

• Classification: structural genomics, unknown function
• Organism(s): Burkholderia pseudomallei K96243
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2008-12-15 Released: 2009-01-13
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.90 Å
• R-Value Free:
  0.219 (Depositor), 0.226 (DCC)
• R-Value Work:
  0.181 (Depositor), 0.186 (DCC)
• R-Value Observed:
  0.183 (Depositor)

Literature

Crystal structure of novel protein of unknown function (YP_111841.1) from BURKHOLDERIA PSEUDOMALLEI K96243 at 1.90 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 44.22 kDa
• Atom Count: 3,357
• Modeled Residue Count: 370
• Deposited Residue Count: 388
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
uncharacterized novel protein	A, B	194	Burkholderia pseudomallei K96243	Mutation(s): 0  Gene Names: BPSS1837, YP_111841.1
UniProt
Find proteins for Q63J81 (Burkholderia pseudomallei (strain K96243)) Explore Q63J81  Go to UniProtKB:  Q63J81

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	C [auth B], D [auth B]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
CL	E [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.90 Å
• R-Value Free:  0.219 (Depositor), 0.226 (DCC)
• R-Value Work:  0.181 (Depositor), 0.186 (DCC)
• R-Value Observed: 0.183 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33FJV

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 35.775	α = 90
b = 90.816	β = 90
c = 131.927	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-01-13
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2009-01-13
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.2: 2017-11-01
  Changes: Refinement description
• Version 1.3: 2019-07-24
  Changes: Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-02-01
  Changes: Database references, Derived calculations
• Version 1.5: 2024-10-30
  Changes: Data collection, Structure summary
