3F1B | pdb_00003f1b

The crystal structure of a TetR-like transcriptional regulator from Rhodococcus sp. RHA1.

• PDB DOI: https://doi.org/10.2210/pdb3F1B/pdb

• Classification: transcription regulator
• Organism(s): Rhodococcus jostii RHA1
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2008-10-27 Released: 2008-11-18
• Deposition Author(s): Tan, K., Evdokimova, E., Kudritska, M., Savchenko, A., Edwards, A., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free:
  0.278 (Depositor), 0.262 (DCC)
• R-Value Work:
  0.225 (Depositor), 0.226 (DCC)
• R-Value Observed:
  0.227 (Depositor)

Literature

The crystal structure of a TetR-like transcriptional regulator from Rhodococcus sp. RHA1.

Tan, K., Evdokimova, E., Kudritska, M., Savchenko, A., Edwards, A., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 22.65 kDa
• Atom Count: 1,410
• Modeled Residue Count: 183
• Deposited Residue Count: 203
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
TetR-like transcriptional regulator	A	203	Rhodococcus jostii RHA1	Mutation(s): 0  Gene Names: RHA1_ro05197, Rhodococcus
UniProt
Find proteins for Q0S658 (Rhodococcus jostii (strain RHA1)) Explore Q0S658  Go to UniProtKB:  Q0S658

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	B [auth A], C [auth A], D [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
EDO	E [auth A]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free:  0.278 (Depositor), 0.262 (DCC)
• R-Value Work:  0.225 (Depositor), 0.226 (DCC)
• R-Value Observed: 0.227 (Depositor)

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.991	α = 90
b = 53.991	β = 90
c = 129.589	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
SHELXD	phasing
MLPHARE	phasing
DM	model building
RESOLVE	model building
HKL-3000	phasing
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling
DM	phasing
RESOLVE	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2008-11-18
Deposition Author(s): Tan, K., Evdokimova, E., Kudritska, M., Savchenko, A., Edwards, A., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2008-11-18
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Refinement description, Source and taxonomy, Version format compliance
• Version 1.2: 2023-12-27
  Changes: Data collection, Database references, Derived calculations
• Version 1.3: 2024-11-13
  Changes: Structure summary
